DIO232 BACHMANN Analog Input/Output Modules

INQUIRE NOW

Products Name: DIO232 BACHMANN Analog Input/Output Modules

PRODUCT DESCRIPTION

Brand: BACHMANN

Model number:DIO232

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.52Kg

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Description:

The digital input / output modules DIO2xx / x

can be used to operate receivers of digital control

devices such as contactors, relays, pneumatic and

hydraulic valves as well as for reading signals from

digitally operating sources such as sensors, photocells or switches.

• 16 / 32 / 48 / 64 or 80 digital channels

• 16 channels can be confi gured as input

or output

• Confi gurable interrupt inputs

• Status display for each channel via LED

• Supply voltage 18 .. 34 V DC

• Supply voltage protected against reverse polarity

• Cost effective and space saving

• Full wiring without extra potential rails

(3-wire, only DIO216)

Inputs

Quantity max. 16 max. 16 16 .. 32 16 .. 32 24 .. 48 32 .. 48

Input voltage range (H) 15 .. 34 V DC

Input voltage range (L) 0 .. 5 V DC

Input delay (normally) 600 μs 0 .. 365 ms 600 μs

Internal resistance 6.8 kOhm

Status indication (LED) green

Interrupt inputs 1 1 8 8 8 8

Outputs

Quantity max. 16 max. 16 max. 16 16 .. 32 24 .. 48 32 .. 48

Output voltage range 18 .. 34 V DC

Output current per channel (max.) 1 A 1 A 0.5 A 0.5 A 0.5 A 0.5 A

Total current (max.) 12 A 16 A 8 A 16 A 20 A 24 A

Status indication (LED) green

Switching frequency

(max., ohmic load) 1 kHz

External power supply

Reverse polarity protection yes

Galvanic isolation from system 500 V

Ambient conditions Standard coldclimate ( )

Operating temperature -30 .. +60°C

Rel. humidity operation 5 .. 95 % without

condensation

5 .. 95% with

condensation

Storage temperature -40 .. +85°C

Rel. humidity storage 5 .. 95 % with condensation

Execution variants

DIO216 digital input / output modules 16x DIO; 24 V / 1 A; 1 group; isolated;

1 interrupt channel; 3-wire technology

DIO216 / 4 digital input / output modules 16x DIO; 24 V / 1 A; 4 groups;

isolated; 1 interrupt channel; 3-wire technology

DIO216 / 4 like DIO216/4; coldclimate design ( )

DIO232 digital input/output modules 16x DIO / 16x DI / 16x DO, 24 V / 0.5 A,

2 groups, isolated; 8 interrupt channels

DIO232 like DIO232; coldclimate design ( )

DIO248 digital input/output modules 16x DIO / 16x DI / 16x DO, 24 V / 0.5 A,

4 groups, isolated; 8 interrupt channels

DIO264 Digital input / output modules 16x DIO / 24x DI / 24x DO, 24 V / 0.5 A,

5 groups, isolated; 8 interrupt channels, CAN-slave

DIO264C digital input / output modules 16x DIO / 24x DI / 24x DO, 24 V / 0.5 A,

5 groups, isolated; 8 interrupt channels

DIO280 digital input / output modules 16x DIO / 32x DI / 32x DO, 24 V / 0.5 A,

6 groups, isolated; 8 interrupt channels

DIO280 like DIO280; coldclimate design


DIO232   BACHMANN  Analog Input/Output Modules
