BENDER IR125Y-4 Central control module

Bender Insulation Monitoring Devices Overview

Bender is an expert in electrical safety, and its Insulation Monitoring Devices (IMDs) are used to monitor the insulation resistance in unearthed (IT) electrical systems. These devices are crucial for ensuring electrical

safety, preventing electrical accidents, and maximizing system uptime.

Product Detailed Description

• Function:

• Continuously monitors the insulation resistance of IT systems.

• Issues alarms when the insulation resistance falls below a preset threshold.

• Helps prevent electrical fires, electric shocks, and equipment damage.

• Some models offer insulation fault location functionality.

• Features:

• Suitable for AC, DC, or AC/DC IT systems.

• Configurable alarm thresholds.

• Multiple communication interfaces (such as Modbus, Ethernet) for remote monitoring.

• Robust design for industrial environments.

Product Parameters

• Monitoring Type:

• Insulation resistance monitoring.

• Applicable Systems:

• AC IT systems, DC IT systems, AC/DC IT systems.

• Voltage Range:

• Varies by model.

• Alarm Thresholds:

• Adjustable.

• Communication Interfaces:

• Modbus RTU/TCP, Ethernet, etc.

• Installation Method:

• DIN rail mounting, panel mounting, etc.

• For detailed parameters, please refer to the official Bender product manual.

Product Advantages

• Improved Electrical Safety:

• Early detection of insulation faults prevents electrical accidents.

• Extended System Uptime:

• Reduced unexpected downtime through preventive maintenance.

• Reduced Maintenance Costs:

• Simplified fault location shortens repair times.

• Increased System Availability:

• Continuous monitoring, early warning, avoid sudden failures.

Precautions

• Correct Installation:

• Follow Bender's installation guidelines.

• Environmental Conditions:

• Ensure the operating environment meets the product's specifications.

• Regular Testing:

• Regularly test the functionality of the insulation monitoring device to ensure it is working properly.

• Safe Operation:

• Follow relevant safety procedures when performing electrical maintenance.

Product Applications

• Medical IT Systems:

• Operating rooms, intensive care units, etc.

• Industrial IT Systems:

• Chemical, oil, gas, etc.

• Data Centers:

• Uninterruptible Power Supply (UPS) systems.

• Renewable Energy:

• Photovoltaic systems, wind power generation systems.

• Electric Vehicle Charging Stations:

• Guarantees the electrical safety of the charging process.
