Upon request, we can provide engineering services to determine the
appropriateness of housing measurements for the machine in question and/or
to provide installation assistance.
Description:
Velocity Transducer Housing Assembly
21128-AXX-BXX
A: Mounting Thread Option
0 1 Unthreaded
0 2 3/4 - 14 NPT
0 3 1/2 - 14 NPT
0 4 1/2 - 12 BSP
B: Cable Exit Fitting Option
0 1 1/2 - 14 NPT plug
0 2 1/2 -14 NPT explosion-proof
0 3 1/2 -14 NPT explosion-proof
with cable gland seal
Note: When using the 21128 housing,
cable part number 89477-AA is
necessary to connect the
Velomitor Sensor to a monitor.
Velocity Transducer Housing – CENELEC approved
107770-AXX-BXX
This version is a combination of the 330500
Velomitor Sensor and a 21128 Housing pre-installed
at the factory. It is also rated for CENELEC Zone 1,
Group IIC hazardous area applications.
A: Mounting Thread Option
0 1 Unthreaded
0 2 3/4 - 14 NPT
0 3 1/2 - 14 NPT
0 4 1/2 - 14 BSP
B: Cable Exit Fitting Option
0 1 1/2 - 14 NPT plug
0 2 1/2 - 14 NPT explosion-proof
0 3 1/2 - 14 NPT explosion-proof
with cable gland seal
Accessories
100076-01
330500 Velomitor Sensor and
Velomitor XA Sensor Manual.
02173006
Bulk cable; 2 conductor 18 AWG
twisted, shielded cable without
connectors or terminal lugs.
Specify number of feet.
46000-01
Magnetic Base for temporary
mounting of Velomitor Sensors.
Used with 1/4 - 28 UNF mounting
thread adapters.
46122-01
Quick Connect for
semi-permanent mounting of
Velomitor Sensors. Used with
1/2 - 20 UNF mounting thread
adapters.
89409-01
Individual 1/2 - 20 UNF
mounting adapter.
89410-01
Individual M8 x 1 mounting
adapter.
89411-01
Individual 1/4 - 28 UNF
mounting adapter.
89412-01
Individual 1/4 - 20 UNC
mounting adapter.
89413-01
Individual 1/4 - 18 NPT mounting
adapter. Spares only. For new
installations, order 330525
velometer.
04300015
Individual 5/8 - 18 UNF
mounting adapter.
161191
Individual 1/2 - 13 UNC
mounting adapter.
Note: The Velomitor Sensor is shipped
with an adapter. Individual
adapters are available as spares.
101212-01
Velomitor Sensor connector kit.
Used with housings and retrofits.
123135-01
Velomitor Sensor Power Module.
