BENTLY 23733-03 Interface module

Product Description

The Bently Nevada 23733-03 is a specialized accelerometer interface module designed to process and transmit vibration signals from accelerometers. It is commonly used in machinery health monitoring systems to

 provide accurate and reliable data for condition-based maintenance.

Key Features and Benefits

• Signal Conditioning: The module transforms the filtered acceleration signal into a velocity signal, enhancing the clarity and interpretability of the data.



• Sensitivity: It offers a high sensitivity of 100 mV/in/s pk (3.94 mV/mm/s pk), allowing for precise measurement of even subtle vibrations.



• Versatility: The module is compatible with a wide range of accelerometers, making it a flexible solution for various applications.

• Reliability: Built to withstand harsh industrial environments, the 23733-03 ensures long-term performance and durability.

• Extended Cable Length: The buffered velocity signal allows for longer cable runs, providing greater installation flexibility.



Technical Specifications

• Part Number: 23733-03



• Function: Accelerometer Interface Module

• Output Signal: Velocity signal

• Sensitivity: 100 mV/in/s pk (3.94 mV/mm/s pk)



• Compatibility: Compatible with various Bently Nevada accelerometers

• Operating Environment: Industrial conditions

• Dimensions and Weight: [Specific dimensions and weight can be found in the product datasheet]

Precautions

• Installation: Follow the manufacturer's guidelines for proper installation to ensure optimal performance and avoid damage.

• Calibration: Regular calibration is recommended to maintain accuracy.

• Environmental Considerations: Protect the module from excessive heat, moisture, and vibration.

• Compatibility: Verify compatibility with other system components before installation.

Applications

• Rotating Machinery Monitoring: Used to monitor the condition of rotating equipment such as turbines, pumps, and compressors.

• Vibration Analysis: Provides data for vibration analysis to detect faults and prevent equipment failures.

• Condition-Based Maintenance: Supports condition-based maintenance programs by enabling early detection of potential problems.
