bently 172103-01 RTD/Isolated Tip TC I/O module

Product Description

The Bently Nevada 172103-01 is an RTD/Isolated Tip TC I/O module designed for temperature monitoring applications. It is a component of the Bently Nevada 3500/65 Temperature Monitor system, providing 16 channels for measuring temperature using either resistance temperature detectors (RTDs) or isolated tip thermocouples (TCs).

Key Features and Specifications

• Channels: 16 channels for temperature measurement



• Input Types: RTD and isolated tip TC



• Dimensions: (Height x Width x Depth) 241.3 mm x 24.4 mm x 99.1 mm



• Weight: 0.45 kg



• Rack Space: 1 full-height rear slot



• Internal Terminations: For direct connection of sensors



Advantages

• Versatility: Accepts both RTDs and isolated tip TCs for flexible temperature measurement.



• Accuracy: Provides accurate temperature readings.

• Reliability: Designed for industrial environments and built to withstand harsh conditions.

• Compatibility: Integrates seamlessly with the Bently Nevada 3500/65 Temperature Monitor system.

• Internal Terminations: Simplifies installation and wiring.

Precautions

• Compatibility: Ensure compatibility with the rest of your system, including the mainframe and other modules.

• Installation: Follow the manufacturer's instructions carefully to ensure correct installation.

• Calibration: Regular calibration is recommended to maintain accuracy.

• Environment: Avoid exposing the module to excessive temperature, humidity, or vibration.

• Maintenance: Follow the manufacturer's maintenance guidelines.

Applications

• Turbine Monitoring: Monitoring the temperature of critical components in turbines, such as bearings, casings, and blades.

• Compressor Monitoring: Monitoring the temperature of compressors and their components.

• Motor Monitoring: Monitoring the temperature of motors and windings.

• Process Monitoring: Monitoring temperature in various industrial processes.

Additional Information

• End of Life: While the product may be end-of-life, it might still be available through third-party suppliers or refurbished markets.

• Replacement: If seeking a replacement, consider newer models from Bently Nevada or compatible alternatives from other manufacturers.

• Support: For technical support or replacement parts, contact Bently Nevada or an authorized distributor.

In summary, the Bently Nevada 172103-01 is a reliable and versatile temperature monitoring module that can be used in a variety of industrial applications. It offers accurate measurements, easy installation, and compatibility with other Bently Nevada products.
