bently 23733-03 Accelerometer Interface Module

Product Description

The Bently Nevada 23733-03 is an accelerometer interface module designed to transform filtered acceleration signals into velocity signals. It is commonly used in machine health monitoring applications to provide valuable insights into the condition of rotating machinery.

Key Features and Benefits

• Signal Transformation: Converts acceleration to velocity, enabling easy integration into velocity-based monitoring systems.



• Sensitivity: Offers a sensitivity of 100 mV/in/s pk (3.94 mV/mm/s pk), providing accurate and reliable velocity measurements.



• Buffering: Includes a buffer for extended cable length connections, enhancing flexibility in system design.



• Reliability: Built to withstand harsh industrial environments and provide long-term, dependable performance.

• Compatibility: Compatible with various Bently Nevada monitoring systems, simplifying integration into existing setups.

Technical Specifications

• Part Number: 23733-03



• Sensitivity: 100 mV/in/s pk (3.94 mV/mm/s pk)



• Voltage: VT (-18 to -24 VDC)



• Dimensions: Approximately 7.8 cm x 6 cm x 5 cm

• Weight: Approximately 0.2 kg

• Country of Origin: USA

Precautions

• Power Supply: Ensure the module is connected to a stable power supply within the specified voltage range.

• Grounding: Proper grounding is essential to minimize noise and interference.

• Environmental Conditions: Avoid exposing the module to excessive temperature, humidity, or vibration.

• Installation: Follow the manufacturer's guidelines for correct installation and wiring.

Applications

• Rotating Machinery Monitoring: Used to monitor the health of various rotating equipment, including turbines, pumps, compressors, and motors.

• Vibration Analysis: Provides accurate vibration measurements for fault detection, diagnosis, and predictive maintenance.

• Condition Monitoring: Helps assess the overall condition of machinery and identify potential problems before they lead to costly failures.

Additional InformationFor more detailed information, including datasheets, installation manuals, and troubleshooting guides, please refer to the official Bently Nevada documentation or contact your local distributor.
