The Eaton NITD20 is a low voltage British standard fuse, specifically designed for general industrial applications.It belongs to the Eaton Bussmann series and is known for its reliability and performance. The fuse is designed to protect electrical circuits from overcurrent conditions, such as short circuits and overloads.
Key Features and Specifications
Voltage Rating: 550 VAC
Current Rating:20 Amperes
Breaking Capacity: 80 kA
Class: gG/gL
Dimensions: 14mm x 55mm
Material: Ceramic and silver
Certifications: IEC 60269-2, BS88, CE marked, RoHS compliant
Advantages
Reliability: Constructed with high-quality materials to ensure long-lasting performance.
Safety: Provides overcurrent protection to safeguard electrical equipment.
Versatility: Suitable for a wide range of applications.
Easy Installation: Standard dimensions for easy replacement.
Compliance:Meets international standards and regulations.
Precautions
Correct Sizing: Always select the correct fuse rating to protect the circuit without unnecessary tripping.
Installation: Ensure proper installation in a compatible fuse holder.
Replacement: Replace the fuse with a fuse of the same type and rating.
Overload:Avoid overloading the circuit, as this can lead to frequent fuse blowing.
Safety: Exercise caution when handling fuses, as they can be hot and may contain hazardous materials.
Applications
The Eaton NITD20 is commonly used in various applications, including:
Industrial Control Panels: Protecting motors, relays, and other electrical components.
Power Distribution: Protecting branch circuits in electrical distribution systems.
Commercial Buildings: Protecting lighting circuits and other electrical loads.
Residential Applications: Protecting electrical circuits in homes and other residential buildings.
Additional Information
Material: The fuse is made of ceramic and silver, which provide excellent electrical and thermal properties.
Marking: The fuse is clearly marked with its rating, voltage, and other relevant information.
Compatibility:The NITD20 is compatible with a wide range of fuse holders and mounting systems.
Conclusion
The Eaton NITD20 is a reliable and versatile fuse that provides essential overcurrent protection for electrical circuits. Its compact size, high performance, and wide range of applications make it a popular choice for electrical engineers and technicians.
