Foxboro E69F-BI2-J Output module

Foxboro E69F-BI2-J Overview

The Foxboro E69F-BI2-J is a capacitive pressure transmitter belonging to Foxboro's line of pressure measurement instruments. It is designed to measure the pressure of liquids, gases, or steam and convert the measured pressure into a standard electrical signal output, typically used in industrial process control applications.

Product Detailed Description

• Function:

• Precisely measures process pressure.

• Converts the measured pressure into an analog current signal proportional to the pressure (typically 4-20 mA).

• Can be used to measure gauge, absolute, or differential pressure (depending on the specific configuration).

• Robust and durable design suitable for various industrial environments.

• Features:

• Capacitive sensor technology providing high accuracy and stability.

• Adjustable range and zero point.

• Wide variety of process connection options.

• Explosion-proof or intrinsically safe certifications available for hazardous areas.

• Optional digital communication protocols (e.g., HART) for remote configuration and diagnostics.

Product Parameters

As the specific configuration of the Foxboro E69F-BI2-J will affect its parameters, the following are some typical parameters for capacitive pressure transmitters. Always refer to the official datasheet for the specific model:

• Measurement Range (Span):

• Varies by specific model, covering a wide range of pressure ranges.

• Output Signal:

• Typically 4-20 mA DC, other signal types may also be available.

• Accuracy:

• Typically ±0.1% of span or better.

• Supply Voltage:

• Typically 24 V DC (loop-powered).

• Process Connection:

• Various threaded connections (e.g., NPT, BSP) and flanged connections.

• Electrical Connection:

• Typically via terminal blocks or cable entries.

• Protection Degree:

• Typically IP66 or higher.

• Operating Temperature:

• Varies depending on the specific model and materials.

• Certifications:

• May include explosion-proof certifications such as FM, CSA, ATEX, IECEx.

• Communication Protocol:

• Optional HART protocol.

Product Advantages

• High Accuracy and Stability:

• Capacitive sensor technology provides reliable measurement performance.

• Robust and Durable:

• Designed for long-term operation in harsh industrial environments.

• Flexibility:

• Adjustable range, various process connections, and output options to suit different application needs.

• Suitable for Hazardous Areas:

• Models with explosion-proof or intrinsically safe certifications are available.

• Supports Digital Communication:

• HART protocol facilitates device configuration, calibration, and diagnostics.

Precautions

• Correct Selection:

• Choose the appropriate model and materials based on the characteristics of the measured medium (e.g., corrosiveness, temperature), pressure range, accuracy requirements, and installation environment.

• Correct Installation:

• Follow Foxboro's installation guidelines, ensuring the transmitter is securely mounted and avoiding mechanical stress.

• Electrical Connections:

• Ensure electrical connections comply with regulations and are properly grounded.

• Environmental Protection:

• Protect the transmitter from extreme temperatures, humidity, and corrosive substances.

• Regular Maintenance and Calibration:

• Periodically inspect the transmitter's performance and calibrate it as needed to ensure measurement accuracy.

Product Applications

• Oil and Gas:

• Pipeline pressure monitoring, tank level measurement (via differential pressure transmitters).

• Chemical Processing:

• Reactor pressure control, process line pressure measurement.

• Power Generation:

• Boiler pressure monitoring, steam pressure measurement.

• Water and Wastewater Treatment:

• Pump discharge pressure monitoring, pipeline pressure measurement.

• Food and Beverage:

• Process pressure control.

• Pharmaceuticals:

• Precise pressure measurement of critical process parameters.
