IDP10-T46C01F-B2 foxboro Programmable controller

Product Description

The Foxboro IDP10-T46C01F-B2 is a versatile electronic differential pressure transmitter designed to provide precise and reliable measurement of differential pressure in various industrial applications. This transmitter is part of the Foxboro IDP10 series, renowned for its accuracy and durability. The specific configuration of this model suggests a 4-20 mA analog output, a specific pressure range, and a particular material of construction.

Key Features and Specifications

• Measurement: Differential pressure



• Output: 4-20 mA analog



• Pressure Range: The specific pressure range will depend on the configuration but is likely in the range of a few inches of water to several hundred psi.

• Accuracy: High accuracy for precise process control.



• Materials of Construction: The "-B2" suffix typically indicates a specific material of construction, such as 17-4 PH stainless steel, which offers excellent corrosion resistance.

• Temperature Range: Wide operating temperature range for various industrial environments.

• Electrical Connections: Typically uses a two-wire connection for power and signal.



Advantages

• Accuracy and Precision: Provides highly accurate and repeatable measurements.



• Reliability: Designed for rugged industrial environments and offers long-term stability.



• Versatility: Can be configured for various pressure ranges and output signals.



• Compatibility: Compatible with a wide range of Foxboro control systems.

• Diagnostics: Built-in diagnostics for easy troubleshooting.

Precautions and Considerations

• Installation: Follow the manufacturer's instructions carefully to ensure proper installation and alignment.

• Process Conditions: Ensure that the process fluid is compatible with the wetted parts of the transmitter.

• Calibration: Regular calibration is recommended to maintain accuracy.

• Overpressure Protection: Avoid exposing the transmitter to pressures that exceed its rated maximum.

• Environmental Conditions: Operate the transmitter within the specified temperature and humidity ranges.

Applications

The Foxboro IDP10-T46C01F-B2 is used in a wide range of industrial applications, including:

• Level Measurement: Measuring liquid level in tanks and vessels.



• Flow Measurement: Calculating flow rate based on differential pressure across an orifice plate or other flow element.



• Pressure Measurement: Measuring differential pressure across filters, valves, and other process equipment.

• Airflow Measurement: Measuring airflow in ducts and ventilation systems.

Additional Information

• Configuration: The transmitter can be configured using appropriate software to set the desired range, units, and other parameters.



• HART Communication: Many IDP10 models support HART protocol, allowing for advanced configuration and diagnostics.

• Accessories: A variety of accessories are available, including mounting brackets, junction boxes, and impulse lines.
