IGP10-T22C1F-L1 FOXBORO Electronic pressure transmitter

Product Description

The Foxboro IGP10-T22C1F-L1 is an electronic pressure transmitter designed to measure and convert gauge pressure into a proportional electrical signal. It is part of the Foxboro IGP10 series, known for its reliability and accuracy in industrial process control applications. This particular model is specifically designed for low-pressure measurements.

Key Features and Specifications

• Measurement: Measures gauge pressure (pressure relative to atmospheric pressure)



• Pressure Range: The specific pressure range will vary depending on the configuration, but this model typically measures low pressures.

• Output Signal: Typically provides a 4-20 mA analog output signal, proportional to the measured pressure.

• Power Supply: Requires a DC power supply (voltage and current ratings will vary depending on the configuration).



• Materials of Construction: Stainless steel or other corrosion-resistant materials are commonly used for wetted parts.

• Process Connections: Available with various process connections to suit different piping systems.

Advantages

• Accuracy: Offers high accuracy and repeatability in pressure measurements.



• Reliability: Designed for rugged industrial environments and provides long-term stability.



• Versatility: Can be configured for various pressure ranges and output signals.

• Compatibility: Compatible with a wide range of Foxboro control systems.

Precautions and Considerations

• Installation: Proper installation is crucial for accurate measurements. Follow the manufacturer's instructions carefully.

• Calibration: Regular calibration is recommended to ensure the accuracy of the transmitter.

• Environmental Conditions: Avoid exposing the transmitter to excessive temperature, humidity, or vibration.

• Overpressure Protection: Ensure that the transmitter is not subjected to pressures that exceed its rated maximum.

• Compatibility: Verify that the transmitter is compatible with your specific application and control system.

Applications

The Foxboro IGP10-T22C1F-L1 is commonly used in various industrial applications, including:

• Process control: Monitoring and controlling pressure in processes such as filtration, distillation, and chemical reactions.

• HVAC: Measuring air pressure in HVAC systems.

• Water and wastewater treatment: Monitoring pressure in pipelines and tanks.

• Oil and gas: Measuring pressure in various process units.

Additional Information

• Data Sheet: For more detailed specifications and technical information, refer to the official Foxboro product data sheet.

• Configuration: The transmitter can be configured to meet specific application requirements using appropriate software and tools.

• Maintenance: Regular maintenance is essential to ensure optimal performance.

To provide a more accurate and customized response, please provide additional information such as:

• Specific pressure range you require.

• Process connection needed.

• Power supply available.

• Any special requirements or limitations.

By providing this information, I can assist you further in selecting the appropriate transmitter and ensuring its proper integration into your system.
