Home / Products / GE FANUC / A06B-6081-H103 GE

A06B-6081-H103 GE

Brand: GE

Model number :A06B-6081-H103

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.2kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

A06B-6081-H103 GE Output Point I/O Module

INQUIRE NOW

Products Name: A06B-6081-H103 GE

PRODUCT DESCRIPTION

This IC693 PLC system DC input power supply is a 30-

watt supply designed for a 12 VDC nominal input. It will

accept an input range of 9.6 to 15.0 VDC. It mounts in a

standard power supply slot in any IC693 PLC baseplate.

This power supply provides three separate outputs:

• +5VDC

• +24VDC Relay Output for powering circuits on

IC693 Relay Output modules

• +24VDC Isolated for powering Input modules

Description:

The + and – wires from the 12 VDC power source

connect to the top two protected terminals on the powers

supply terminal board. Connect the + wire to the top

terminal and the – wire to the second terminal. A

connection diagram is printed on the front of the power

supply module next to the terminal board.

Isolated 24 VDC Supply

The bottom two terminal board terminals provide

connections to the Isolated 24 VDC output. This output

can be used to provide power for input circuits for 24

VDC Input Modules (within the 15 watt limitation of this

output). This is useful because power switched to input

points must be supplied from a source external to the

IC693 input modules.

Wire Connection information

• Each terminal can accept solid or stranded wires, but,

if using two wires on one terminal, the wires should

be the same size and type.

• The suggested torque for the power supply terminal

board screws is 12 in-lbs. (1.36 Nm).

• Use one AWG #14 (2.1 mm2

) or two AWG #16 (1.3

mm2

) copper conductors, rated for 75 degrees C (167

degrees F) only, per terminal board terminal.

Input Overvoltage Protection Devices

The input overvoltage protection devices are connected

internally to pin 4 of the terminal board. This pin is

normally connected to pin 3 (frame ground) via a factoryinstalled jumper strap. If a Hi-Pot test is to be performed

on this supply, the jumper strap must be removed during

the test so that the overvoltage protection devices are not

damaged. After testing, replace the jumper strap to

restore overvoltage protection during normal operation.



Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
