GE IC200UDR010 Output module

GE VersaMax Micro PLC IC200UDR010 Overview

The GE VersaMax Micro PLC IC200UDR010 is a compact and cost-effective Programmable Logic Controller (PLC) suitable for a variety of industrial automation applications. It offers integrated digital and analog I/O points, as well as communication interfaces for flexible control solutions.

Product Detailed Description

• Function:

• Controls industrial automation processes and machines.

• Executes logic operations, timing, counting, and PID control functions.

• Interacts with field devices (sensors, actuators, etc.) through integrated I/O interfaces.

• Exchanges data with other control systems or devices through communication interfaces.

• Programmable using GE Proficy Machine Edition software.

• Features:

• Compact design, saving installation space.

• Integrated 20 digital input points (24 VDC sinking/sourcing).

• Integrated 12 digital output points (24 VDC transistor sourcing).

• Integrated 2 analog input channels (0-10V or 0-20mA).

• Integrated 1 analog output channel (0-10V or 0-20mA).

• Integrated RS-232 and RS-485 serial communication ports.

• Supports various communication protocols, including Modbus RTU and SNP.

• Expandable I/O modules (via VersaMax Micro expansion modules).

• LED indicators for diagnostics and status display.

• DIN rail mounting.

Product Parameters

• CPU:

• Features processing power to execute control logic.

• Program Memory:

• Capacity allows storage of user-written control programs.

• Data Memory:

• Capacity for storing variables, states, and other data.

• Digital Inputs (DI):

• 20 points, 24 VDC sinking/sourcing.

• Digital Outputs (DO):

• 12 points, 24 VDC transistor sourcing, maximum current capacity please refer to the manual.

• Analog Inputs (AI):

• 2 channels, 0-10V or 0-20mA configurable.

• Resolution please refer to the manual.

• Analog Outputs (AO):

• 1 channel, 0-10V or 0-20mA configurable.

• Resolution please refer to the manual.

• Communication Ports:

• 1 x RS-232.

• 1 x RS-485.

• Communication Protocols:

• Modbus RTU (Master/Slave).

• SNP.

• Expansion I/O:

• Supports VersaMax Micro expansion modules.

• Power Supply:

• 24 VDC.

• Power consumption please refer to the manual.

• Operating Temperature:

• Please refer to the manual.

• Protection Rating:

• Please refer to the manual.

• Dimensions and Weight:

• Compact size, specific dimensions please refer to the manual.

• Weight please refer to the manual.

• Certifications:

• Please refer to the manual.

Product Advantages

• Compact and Cost-Effective:

• Small size and competitive price, suitable for budget-conscious applications.

• Integrated I/O:

• Integrated digital and analog I/O points reduce the need for additional modules, lowering cost and complexity.

• Flexible Communication:

• Supports multiple serial communication protocols for easy integration with other devices.

• Scalability:

• I/O capacity can be expanded using VersaMax Micro expansion modules to accommodate future needs.

• Reliability:

• GE brand, offering industrial-grade reliability.

• Easy Programming:

• Programmed using the powerful GE Proficy Machine Edition software.

Precautions

• Correct Installation:

• Follow GE's installation guidelines, ensuring the PLC is installed in a suitable environment and wired correctly.

• Power Requirements:

• Use a 24 VDC power supply that meets the specifications.

• Environmental Conditions:

• Ensure the operating environment temperature and humidity are within the permissible range.

• Wiring:

• Carefully check and connect I/O devices and communication lines according to the wiring diagrams.

• Programming:

• Use GE Proficy Machine Edition software for correct logic programming and configuration.

• Maintenance:

• Regularly check the PLC's status indicators and connections to ensure proper operation.

• EMC Considerations:

• Take appropriate Electromagnetic Compatibility (EMC) measures to reduce electromagnetic interference.

Product Applications

The GE VersaMax Micro PLC IC200UDR010 is suitable for various industrial automation applications, including but not limited to:

• Small Machine Control:

• E.g., packaging machines, labeling machines, small conveyor systems.

• HVAC (Heating, Ventilation, and Air Conditioning) Control:

• Controlling fans, valves, and actuators.

• Water Treatment:

• Controlling pumps, valves, and monitoring equipment.

• Material Handling:

• Controlling simple conveyor belts and sorting systems.

• Building Automation:

• Controlling lighting, security systems, etc.

• OEM Applications:

• Integration into various Original Equipment Manufacturer (OEM) equipment.
