GE IC693CPU313 Programmable controller

GE Fanuc/Emerson VersaMax IC693CPU313 Overview

The GE Fanuc/Emerson VersaMax IC693CPU313 is a central processing unit (CPU) module for the VersaMax Programmable Logic Controller (PLC) system. It's a compact and cost-effective CPU designed for a variety of industrial automation applications.

Product Detailed Description

• Function:

• Executes the control program stored in its memory.

• Communicates with I/O modules to read input signals and control output devices.

• Performs logic, arithmetic, and data manipulation operations.

• Provides communication interfaces for programming, monitoring, and networking.

• Features:

• Compact design.

• Cost-effective solution for small to medium-sized applications.

• Offers various memory options for program and data storage.

• Supports a range of communication protocols.

• Compatible with the extensive VersaMax I/O module family.

• Real-time clock for time-stamping and time-based control.

Product Parameters

Please note that specific parameters can vary depending on the exact revision and configuration. Always refer to the official GE Fanuc/Emerson VersaMax hardware reference manual for the most accurate data for a specific IC693CPU313 module. However, here are some typical parameters:

• Processor:

• GE Fanuc proprietary processor.

• Program Memory:

• Typically 4K words (expandable on some revisions).

• Data Memory (Registers):

• Typically 2048 words (expandable on some revisions).

• High-Speed Counter:

• Typically one or two high-speed counters, depending on the revision.

• Pulse Output:

• Typically one or two pulse outputs, depending on the revision.

• Communication Ports:

• One RS-232 port for programming and communication.

• Some revisions may include an additional RS-485 port.

• Real-Time Clock:

• Built-in with battery backup.

• Scan Rate:

• Typically around 0.4 ms per K of Boolean logic.

• Power Supply:

• Requires 5V DC power supplied through the backplane.

• Operating Temperature:

• Typically 0°C to 60°C (32°F to 140°F).

• Dimensions:

• Compact, single-slot module.

• Weight:

• Approximately 0.2 kg (0.44 lbs).

Product Advantages

• Cost-Effective:

• Provides a budget-friendly solution for many control applications.

• Compact Size:

• Saves valuable panel space.

• Reliable Performance:

• Proven technology from GE Fanuc/Emerson.

• Versatile Communication:

• Offers essential communication interfaces for programming and basic networking.

• Compatibility:

• Seamlessly integrates with the wide range of VersaMax I/O modules.

• Real-Time Clock:

• Enables time-based control and data logging.

Precautions

• Correct Installation:

• Install the CPU module in the designated slot of a VersaMax backplane.

• Ensure proper grounding and wiring according to the VersaMax hardware reference manual.

• Power Supply:

• Provide a stable and correct 5V DC power supply.

• Environmental Conditions:

• Operate within the specified temperature and humidity ranges.

• Avoid exposure to excessive vibration, shock, and dust.

• Programming:

• Use the appropriate GE Fanuc/Emerson programming software (e.g., Proficy Machine Edition) to program the CPU.

• Follow proper programming practices to ensure correct and safe operation.

• ESD Sensitivity:

• Handle the CPU module with care to avoid electrostatic discharge (ESD) damage. Use appropriate ESD protection measures.

• Battery Replacement:

• The real-time clock battery will eventually need replacement. Follow the instructions in the hardware reference manual for safe replacement.

Product Applications

The GE Fanuc/Emerson VersaMax IC693CPU313 is commonly used in a variety of industrial automation applications, including:

• Machine Control:

• Controlling various types of industrial machinery.

• Material Handling:

• Automation of conveyors, sorting systems, and other material handling equipment.

• Packaging Machinery:

• Control of filling, labeling, and wrapping machines.

• Small to Medium Process Control:

• Basic control of temperature, pressure, and flow in certain processes.

• Building Automation:

• Control of HVAC, lighting, and security systems.

• OEM Applications:

• Integrated into various original equipment manufacturer (OEM) products.

Remember to always consult the official GE Fanuc/Emerson documentation for the most accurate and up-to-date information regarding the IC693CPU313 module you are using.
