GE IC693TCM302B High-speed communication module

E IC693TCM302B Overview

The GE IC693TCM302B is a high-speed communication module belonging to the GE Fanuc (now Emerson) Series 90-30 PLC (Programmable Logic Controller) family. It is primarily used to establish high-speed serial communication links between the Series 90-30 PLC system and other devices. This module supports various communication protocols.

Product Detailed Description

• Function:

• Provides one high-speed serial communication port for connecting the Series 90-30 PLC system to various external devices such as operator interfaces, printers, other PLCs, or computer systems.

• Supports multiple serial communication protocols, including SNP (Series 90 Protocol), SNP-X, RTU Slave, ASCII In/Out, and Modbus RTU Master/Slave.

• Allows the PLC system to exchange data and control signals with other devices.

• Typically used in applications requiring fast and reliable serial communication.

• Features:

• High-speed serial interface.

• Multi-protocol support, offering flexible communication options.

• Configurable communication parameters (such as baud rate, data bits, stop bits, parity).

• Easy integration into the Series 90-30 PLC system.

• Requires configuration and programming in the PLC CPU module to function.

Product Parameters

• Product Line:

• Series 90-30

• Module Type:

• High-Speed Communication Module

• Number of Communication Ports:

• 1

• Communication Standard:

• RS-232 and RS-422/485 configurable

• Supported Protocols:

• SNP (Series 90 Protocol)

• SNP-X

• RTU Slave

• ASCII In/Out

• Modbus RTU Master

• Modbus RTU Slave

• Baud Rate:

• Configurable, up to 115.2 kbps

• Data Bits:

• Configurable

• Stop Bits:

• Configurable

• Parity:

• Configurable

• Current Consumption:

• Typically low, refer to the official manual for specific values

• Slot Compatibility:

• Can be installed in any I/O slot of the Series 90-30 PLC rack

• Connector Type:

• DB-9 (for RS-232)

• Terminal block (for RS-422/485)

• Ambient Temperature:

• Operating Temperature: 0 °C to +60 °C (varies by specific model and installation environment)

• Storage Temperature: -40 °C to +85 °C (varies by specific model)

• Humidity:

• 5% to 95% non-condensing

• Certifications:

• UL, cUL, CE (refer to the specific product manual)

Product Advantages

• High-Speed Communication:

• Provides fast data transfer rates, suitable for applications requiring real-time communication.

• Multi-Protocol Support:

• Enables communication with a wide range of devices using different communication protocols, increasing system flexibility.

• Easy Integration:

• Specifically designed for the Series 90-30 PLC system, ensuring easy installation and configuration.

• High Reliability:

• GE Fanuc/Emerson products are known for their industrial-grade reliability.

• Flexible Configuration:

• Communication parameters can be configured according to specific application requirements.

Precautions

• Correct Installation:

• Install the module correctly into the Series 90-30 PLC rack according to GE Fanuc's installation guidelines.

• Power Requirements:

• The module is powered by the PLC rack; ensure a stable and reliable PLC power supply.

• Correct Wiring:

• Connect the communication cables correctly to the corresponding ports (DB-9 or terminal block) on the module according to the wiring diagram.

• Parameter Configuration:

• Use GE Fanuc's programming software (such as Proficy Machine Edition) to configure the module's communication protocol and parameters correctly to ensure compatibility with external devices.

• Software Programming:

• Write the corresponding communication logic in the PLC program to implement data transmission and reception.

• EMC Considerations:

• Take appropriate electromagnetic compatibility (EMC) measures to reduce electromagnetic interference and ensure stable communication.

• Consult the Manual:

• Before installing, configuring, and using, be sure to read the official user manual for the GE IC693TCM302B for more detailed technical information and precautions.

Product Applications

The GE IC693TCM302B high-speed communication module is widely used in various industrial automation fields requiring high-speed serial communication with the Series 90-30 PLC system, including but not limited to:

• Human-Machine Interface (HMI) Connection:

• Connecting operator control panels for data monitoring and control.

• Printer Interface:

• Connecting printers for printing alarm messages, reports, etc.

• Communication with Other PLCs:

• Exchanging data between multiple Series 90-30 PLC systems or with PLC systems from other manufacturers.

• Computer System Integration:

• Connecting to computer monitoring systems or data acquisition systems.

• Modbus Networks:

• Acting as a Modbus RTU Master or Slave to communicate with other Modbus devices.

• Barcode Scanners and Serial Devices:

• Connecting various industrial devices with serial interfaces.
