Products Name: SR469-P5-HI-A20-E GE Motor Management Relay
PRODUCT DESCRIPTION
Product Overview
The GE Multilin SR469-P5-HI-A20-E is a versatile motor management relay designed to monitor and protect electric motors in a variety of industrial applications.It provides comprehensive motor protection features, including overload, phase unbalance, ground fault, and thermal overload protection.This relay is equipped with an enhanced display for easy configuration and monitoring.
Key Features and Specifications
Motor Protection: Offers a wide range of motor protection functions, including overload, phase unbalance, ground fault, and thermal overload.
Enhanced Display: Provides clear and easy-to-read information about the motor's status and parameters.
Configurable Load Shed: Allows for selective load shedding based on predefined conditions.
Analog Outputs: Provides 4-20 mA analog outputs for monitoring motor parameters.
Communication: Supports RS485 communication for integration into larger automation systems.
Certifications: Meets various international safety standards, including UL, CSA, and CE.
Control Power: 90-300 VDC, 70-265 VAC @ 48-62 Hz.
Phase CT Secondaries: 5 Amp.
Analog Current Output Accuracy: ±1% of full scale.
Advantages
Comprehensive Protection: Protects motors against a wide range of faults.
Easy Configuration: User-friendly interface for quick and easy setup.
Flexibility: Can be adapted to various motor types and applications.
Reliability: Built with high-quality components for long-term operation.
Integration: Seamlessly integrates into larger automation systems.
Precautions
Installation: Must be installed by a qualified technician in accordance with the manufacturer's instructions.
Wiring: Ensure correct wiring to avoid damage to the relay and connected equipment.
Calibration: Periodic calibration is recommended to maintain accuracy.
Environment: Avoid exposing the relay to excessive heat, cold, or humidity.
Applications
Industrial Motors: Protection of motors in various industrial applications, such as pumps, fans, conveyors, and compressors.
HVAC Systems: Protection of motors used in HVAC systems.
Process Control: Monitoring and protection of motors in process control systems.
Additional Information
Technical Documentation: Refer to the official GE Multilin product documentation for detailed specifications and programming instructions.
Customization: The relay can be customized to meet specific application requirements.
Replacement: When replacing the relay, ensure that the replacement part is compatible with the existing system.
For more detailed information and specific product recommendations, please refer to the GE Multilin product catalog or consult with a GE authorized distributor.
