GKS05-3M HAR 090C12 Lenze APM Modem Card

1. Product Description

A Lenze AC Drive, also known as a Variable Frequency Drive (VFD) or Inverter, is an electronic device used to control the speed, torque, and direction of an AC induction motor. By converting the incoming fixed-frequency AC power to adjustable frequency and voltage AC power, it allows for precise motor control. Lenze AC drives are known for their robustness, efficiency, and advanced control features, making them suitable for a wide range of industrial and commercial applications. They typically include features like digital and analog inputs/outputs, communication interfaces (e.g., EtherNet/IP, Profinet, Modbus), and parameterization via a keypad or PC software (like Lenze’s WIZcon).

2. Product Parameters (Typical Range - Varies by Model)

• Rated Motor Power: Ranges from a few hundred watts (e.g., 0.37 kW) up to several hundred kilowatts (e.g., 500 kW or more), depending on the specific drive series and model.

• Rated Output Voltage: Commonly 230V AC, 400V AC (3-phase), 600V AC, etc.

• Rated Output Current: Corresponds to the motor size it can drive, typically ranging from a few amps to several hundred amps.

• Control Modes: Vector control (Flux Vector, Sensorless Vector), V/f control.

• Communication Interfaces: Ethernet (EtherNet/IP, Profinet, EtherCAT), Fieldbus (Modbus RTU/TCP, Profibus DP), often multiple options per drive.

• Analog Inputs: Typically 2 or more, for speed reference, torque control, etc.

• Analog Outputs: Typically 1 or 2, for speed feedback, current feedback, etc.

• Digital Inputs: Typically 6 or more, for start/stop, forward/reverse, fault reset, etc.

• Digital Outputs: Typically 2 or more, for fault indication, run status, etc.

• Power Factor Correction (PFC): Often available as an option or standard feature to improve power quality.

• Braking Chopper Resistor: Often required for applications with frequent braking or high inertia loads.

• Operating Temperature: Typically -10°C to +50°C (or wider ranges for specific models).

• Protection Rating: Usually IP21S for wall-mounted units.

(Note: Specific values for these parameters depend entirely on the exact model number of the Lenze AC drive.)

3. Product Advantages

• Energy Savings: Allows motors to run at optimal speeds for the required load, significantly reducing energy consumption compared to fixed-speed operation, especially in applications like pumps and fans.

• Precise Speed and Torque Control: Enables smooth acceleration/deceleration and accurate control of motor speed and torque, improving process control and product quality.

• Soft Start/Stop: Reduces mechanical stress on the motor, connected equipment, and the power supply network by avoiding sudden inrush currents and torque spikes.

• Process Optimization: Enhances process efficiency and flexibility by adapting motor speed to real-time process requirements.

• Robust Design & Reliability: Lenze drives are built to withstand harsh industrial environments, offering long service life and high reliability.

• Advanced Diagnostics & Communication: Features comprehensive fault detection, monitoring capabilities, and easy integration into automation networks via various communication protocols.

• Compact Size & Flexibility: Many models offer a high power density in a compact housing, saving valuable control panel space. Wide voltage and frequency ranges offer flexibility for global use.

• User-Friendly Interface: Often includes intuitive parameterization via a keypad and powerful configuration software (WIZcon) for PC-based setup and monitoring.

4. Precautions

• Electrical Safety: AC drives involve high voltages. Only qualified personnel should install, commission, or service the drive. Always de-energize the power supply and discharge capacitors before working on the drive or connected motor.

• Proper Grounding: Ensure correct and secure grounding of the drive and motor according to local electrical codes and manufacturer instructions to prevent shock hazards and equipment damage.

• Correct Wiring: Verify all power, control, and feedback wiring connections before powering on. Incorrect wiring can cause immediate damage or unsafe operation.

• EMC Compliance: Install the drive according to EMC guidelines (shielding cables, proper grounding) to prevent electromagnetic interference with other equipment and to ensure the drive operates correctly.

• Derating: In high ambient temperatures or at high altitudes, the drive’s output current capacity may need to be derated. Refer to the datasheet for specific derating curves.

• Proper Motor Selection: Use only motors specified by Lenze for use with the drive. Incorrect motor selection can lead to overheating, failure, or inaccurate control.

• Braking Resistor: Ensure a properly sized braking resistor is connected if the application involves frequent braking or high inertia loads to prevent overvoltage faults and damage to the drive.

• Software Updates: Use only authorized Lenze software and firmware updates, following the recommended procedures.

5. Product Applications

Lenze AC drives are versatile and used across numerous industries:

• Material Handling: Conveyors, cranes, hoists, lifts – for precise speed control and smooth operation.

• Pumps and Fans: HVAC systems, water treatment plants, chemical processing – for significant energy savings by adjusting flow rates.

• Machine Tools: CNC machines, lathes, milling machines – for precise spindle speed control and axis movement.

• Packaging Machinery: Fillers, sealers, labelers, bottling lines – for coordinated speed control of various machine sections.

• Textile Industry: Spinning machines, weaving looms, dyeing machines – for controlling motor speeds in complex processes.

• Food and Beverage: Mixers, pumps, conveyors, packaging lines – for hygienic designs (where available) and precise control.

• Water and Wastewater: Pumping stations, aerators, mixers – for efficient flow and level control.

• Automation and Robotics: Driving actuators, robotic joints, and handling equipment for precise positioning and speed.

• Wind Energy: Pitch control systems and other auxiliary motor controls.

• Mining and Cement: Conveyor systems, crushers, mills – for high-power, robust motor control in harsh environments.
