I5DAE137F10V10000S 0.37kW Lenze Input module

1. Product Description

The Lenze I5DAE137F10V10000S is an AC drive (Variable Frequency Drive - VFD) designed for controlling the speed, torque, and direction of AC induction motors. It belongs to Lenze’s product line, likely the ECODRIVE series or a similar industrial drive family. This specific unit is rated for a motor power of 0.37 kW (370 W). The drive converts fixed-frequency, fixed-voltage AC power from the mains supply into adjustable-frequency, adjustable-voltage AC power suitable for the connected motor. This allows for precise control of motor speed, leading to significant energy savings, improved process control, and enhanced machine performance.

2. Product Parameters (Typical for this class - Exact values should be verified from the specific datasheet)

• Product Code: I5DAE137F10V10000S

• Brand: Lenze

• Product Type: AC Drive / VFD

• Rated Motor Power: 0.37 kW (370 W)

• Rated Motor Current: Typically around 1.1 - 1.5 A (at 400V) - Check datasheet for exact value

• Rated Motor Voltage: Typically 230V / 400V AC - Check datasheet for exact configuration

• Supply Voltage: Typically single-phase 200-240V AC or three-phase 200-240V AC - Check datasheet for exact configuration

• Control Methods: V/f control, possibly sensorless vector control

• Frequency Range: Typically 0 - 650 Hz (adjustable)

• Protection Class: IP20 (front panel), IP21 or higher for optional enclosure

• Mounting: Wall-mountable

• Communication Options: Often includes basic digital/analog inputs/outputs; may support standard fieldbus protocols like Modbus RTU via optional module or firmware.

• Dimensions: Typically compact, e.g., approx. 100mm (W) x 80mm (H) x 150mm (D) - Check datasheet for exact dimensions

• Weight: Typically around 0.5 - 1 kg - Check datasheet for exact weight

3. Product Advantages

• Energy Savings: By allowing motors to run at optimal speeds for the load demand, significant energy consumption reductions can be achieved compared to fixed-speed operation.

• Precise Speed Control: Enables smooth and accurate adjustment of motor speed over a wide range, improving process quality and machine performance.

• Torque Control: Provides excellent starting torque and precise torque control, beneficial for applications with varying loads.

• Reduced Mechanical Stress: Soft start and soft stop features minimize mechanical shocks, reducing wear and tear on the motor, belts, bearings, and driven equipment, leading to longer equipment life.

• Process Optimization: Allows for better control of processes such as mixing, pumping, and ventilation, leading to improved efficiency and product quality.

• Flexibility: Offers a wide range of programmable parameters for adapting to various application requirements.

• Reliability: Lenze is known for manufacturing robust and reliable industrial drives.

• Compact Design: Often features a small footprint, saving valuable panel space.

4. Precautions

• Electrical Safety: High voltages are present. Installation, wiring, and maintenance must only be performed by qualified personnel. Follow all local electrical codes and safety regulations.

• Proper Wiring: Ensure correct connection of motor leads (L1, L2, L3) and power supply. Incorrect wiring can damage the drive or motor.

• Grounding: Ensure proper and secure grounding of the drive and motor according to local regulations to prevent electrical hazards and interference.

• Motor Compatibility: Use the drive with a motor that is compatible with VFD operation. Standard motors may require derating or specific VFD-rated motors for high performance or continuous duty.

• Harmonics and Interference: VFDs can generate electrical noise (harmonics). Use appropriately sized and shielded cables, especially for long motor leads, and consider installing line reactors or harmonic filters if required by the system or grid regulations.

• Overheating: Ensure adequate ventilation and do not block the drive’s cooling fins or fan. Operate within the specified ambient temperature range.

• Parameter Settings: Incorrect parameter settings can lead to improper operation or damage. Configure parameters carefully, referring to the manual. Restore factory defaults if unsure before reconfiguration.

• Maintenance: While generally robust, periodic checks (e.g., fan operation, cable connections) are advisable.

5. Product Applications

The Lenze I5DAE137F10V10000S, with its 0.37 kW rating, is suitable for a wide range of light industrial and commercial applications requiring precise motor control:

• Pumps: Controlling the speed of small water pumps (e.g., for irrigation, domestic water systems, small HVAC units) to match flow requirements, saving energy.

• Fans: Regulating the speed of small ventilation fans (e.g., in server rooms, small industrial booths, fume hoods) for optimal airflow and energy efficiency.

• Conveyors: Controlling the speed of small belt or roller conveyors in packaging, assembly, or sorting lines.

• Machine Tools: Driving small spindle motors or auxiliary drives in light machinery.

• Mixers and Agitators: Controlling the speed of small mixing or agitating devices in laboratory or small-scale production.

• Textile Machinery: Controlling small motors in textile processing equipment.

• Food and Beverage Processing: Driving small pumps, mixers, or conveyors where precise speed control is needed.

• Automation: Controlling motors in small automation cells or robotic applications.
