Product Detailed Description
Function: The core function of the ADC5483-D200418 is to provide stable DC power for electrical devices, most notably the Valvcon ADC-Series electric actuators. It acts as the bridge between the facility's AC power supply and the DC power requirements of the actuator's internal electronics and motor.
Power Conversion: It takes an AC input (typically 115 VAC or 230 VAC) and converts it to a regulated DC output (specifically 28 VDC). This conversion is crucial for the proper functioning of the actuator's control board, motor, and any optional accessories.
Integration: It's an integral component for the operation of Valvcon ADC-Series actuators, which are known for their continuous duty performance and versatility in valve and damper applications.
Robust Design: As an industrial power supply, it's expected to be built for reliability and to withstand typical industrial operating conditions.
Product Parameters
Based on available information (likely from product listings, as a detailed datasheet for only the power supply module is less common than for the full actuator):
Type: Power Supply Module
Model Number: ADC5483-D200418
Input Voltage: 115 VAC / 230 VAC (selectable or auto-sensing, typically 50/60Hz)
Input Current: 6.3 Amp (at input)
Output Voltage: 28 VDC
Output Current: 9 Amp (DC output)
Dimensions (Approximate): 7" x 5.5" x 3" (approx. 17.8 cm x 14 cm x 7.6 cm)
Associated Product Series: Valvcon ADC-Series Electric Actuators (and potentially other Metso/Valmet control components).
(Note: Without a direct official datasheet for this specific module, these parameters are compiled from various vendor listings and may be subject to confirmation from official Valmet documentation.)
Product Advantages
Reliable Power Conversion: Provides stable and consistent DC power crucial for the reliable operation of sensitive electronic components within the actuators.
Compatibility: Specifically designed to integrate seamlessly with Metso Valvcon ADC-Series electric actuators, ensuring optimal performance.
Dual Voltage Input: The ability to accept both 115 VAC and 230 VAC input makes it versatile for different regional power standards.
Industrial Grade: As a component within an industrial automation product, it's expected to meet industrial standards for durability and performance.
Precautions
Correct Voltage Input: Always verify that the input AC voltage matches the module's specified range (115 VAC or 230 VAC) to prevent damage.
Professional Installation: Installation should be performed by qualified personnel, adhering to all local electrical codes and safety regulations.
Proper Wiring: Ensure all electrical connections (input AC, output DC) are correctly wired, secure, and properly grounded to prevent electrical hazards and ensure stable operation.
Environmental Conditions: Install the module within the specified operating temperature and humidity ranges to ensure its longevity and performance. Avoid excessive dust, moisture, and corrosive environments.
Overload Protection: Ensure that the total current drawn by the connected devices (e.g., actuator) does not exceed the module's maximum output current (9 Amp at 28 VDC) to prevent damage to the power supply.
Maintenance: While power supply modules generally require little maintenance, ensure adequate ventilation around the module to prevent overheating.
Product Applications
The METSO ADC5483-D200418 power supply module is primarily used in applications where Metso/Valmet Valvcon ADC-Series electric actuators are deployed. These actuators are widely used in:
Process Industries: Control valves and dampers in pulp & paper, mining, oil & gas, chemical, and petrochemical plants for flow, pressure, and level control.
HVAC Systems: Operating dampers and valves in large industrial or commercial HVAC systems.
Water & Wastewater Treatment: Controlling valves in various stages of water treatment processes.
Power Generation: Valve and damper control within power plants.
General Manufacturing: Any industrial application requiring automated quarter-turn valve or damper actuation with an electric actuator.
Systems with Valvcon ADC-Series Actuators: It is an essential component for integrating these specific electric actuators into control systems.
