Mitsubishi TS5690N9036 Central control module

Product Description

Mitsubishi Electric is a leading manufacturer of IGBT (Insulated Gate Bipolar Transistor) modules, which are power semiconductor devices widely used in industrial applications. These modules serve as the heart

of power electronic systems, offering efficient power conversion and control.

Key Features and Specifications

• High Power Density: Mitsubishi IGBT modules are designed to handle high power levels in a compact package, enabling efficient power conversion.

• Fast Switching Speed: These modules offer fast switching speeds, reducing switching losses and improving overall system efficiency.

• Robustness: Mitsubishi IGBT modules are designed to withstand harsh operating conditions, including high temperatures, vibration, and electrical transients.

• Wide Voltage and Current Ratings: A broad range of voltage and current ratings is available to suit various applications.

• Built-in Protection Features: Many modules incorporate built-in protection features such as short-circuit protection, overcurrent protection, and thermal shutdown.

Advantages of Mitsubishi IGBT Modules

• High Efficiency: Mitsubishi IGBT modules offer high efficiency, reducing energy consumption and operating costs.

• Reliability: These modules are renowned for their reliability and long service life.

• Versatility: Mitsubishi IGBT modules can be used in a wide range of applications, including motor drives, power supplies, inverters, and renewable energy systems.

• Customization: Mitsubishi can provide customized solutions to meet specific customer requirements.

Precautions and Considerations

• Thermal Management: Adequate heat sinking is essential to prevent overheating and ensure reliable operation.

• Gate Drive: Proper gate drive circuits are required to control the IGBT module effectively.

• Parasitic Inductance: Minimize parasitic inductance in the circuit to prevent voltage spikes and potential damage.

• Layout: Careful circuit layout is crucial to avoid electromagnetic interference and ensure optimal performance.

Applications

Mitsubishi IGBT modules find extensive use in various industries, including:

• Industrial Automation: Motor drives, power supplies, and inverters for industrial machinery.

• Renewable Energy: Solar inverters, wind turbine converters, and energy storage systems.

• Automotive: Electric vehicle charging stations, traction inverters, and auxiliary power supplies.

• Railways: Locomotive drives and traction control systems.

Specific Product Lines

Mitsubishi offers several product lines of IGBT modules, each tailored to specific applications:

• CM Series: General-purpose IGBT modules for a wide range of applications.

• PM Series: High-performance IGBT modules for demanding applications such as motor drives.

• FS Series: Fast switching IGBT modules for high-frequency applications.

• LV100 Series: Low-voltage IGBT modules for compact and efficient power conversion.

Shipping Port: China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
