Product Description
The NI cDAQ-9171 is a compact, one-slot USB chassis designed to work seamlessly with a wide range of C Series I/O modules. This versatile device serves as the foundation for various data acquisition and control
applications, offering flexibility and precision.
Key Features and Specifications
Compact Design: Its small form factor makes it ideal for portable or space-constrained applications.
USB 2.0 Interface: Provides a high-speed connection to a host computer.
One Slot: Accommodates a single C Series module for customized I/O.
Over 60 Compatible Modules: Supports a broad array of sensor-specific I/O modules with integrated signal conditioning.
Temperature Range: Operates reliably in environments ranging from -20°C to 55°C.
Performance: Performance characteristics vary depending on the specific C Series module installed and the number of channels in the task.
Advantages
Flexibility: The modular design allows you to tailor the system to your exact measurement needs by choosing the appropriate C Series module.
Ease of Use: The cDAQ-9171 integrates seamlessly with NI software, such as LabVIEW, making configuration and programming straightforward.
Reliability: Built with high-quality components, the cDAQ-9171 offers robust performance in demanding environments.
Cost-Effective: It provides a cost-effective solution for many measurement and automation tasks.
Important Considerations
Module Compatibility: Ensure that the selected C Series module is compatible with your application requirements and the cDAQ-9171 chassis.
Power Requirements: Verify the power requirements of both the chassis and the installed module.
Environmental Conditions: Operate the cDAQ-9171 within the specified temperature and humidity ranges.
Grounding: Proper grounding is essential to minimize noise and ensure accurate measurements.
Applications
The NI cDAQ-9171 is widely used in a variety of industries and applications, including:
Test and Measurement: Acquiring data from sensors for quality control and product testing.
Industrial Automation: Monitoring and controlling industrial processes.
Research and Development: Conducting experiments and prototyping new systems.
Education: Teaching data acquisition and control concepts.
