SHC68-C68-RDIO2 NI Output module

NI PXI Express chassis is a modular instrumentation platform based on the PXI (PCI eXtensions for Instrumentation) standard, used to build high-performance test, measurement, and control systems. It provides

a rugged chassis with power, cooling, and a high-speed backplane for installing PXI and PXI Express modules.

Product Detailed Description

• Modular Design:

• PXI Express chassis supports a wide range of PXI and PXI Express modules, allowing users to flexibly configure systems as needed.

• High-Speed Backplane:

• The PXI Express backplane provides high-bandwidth data transfer, supporting communication between high-speed instrument modules.

• Power and Cooling:

• The chassis provides stable power and efficient cooling to ensure reliable module operation.

• Timing and Synchronization:

• PXI Express chassis provides precise timing and synchronization capabilities for synchronizing multiple instrument modules.

Product Parameters

• Number of Slots:

• Different chassis models offer different numbers of slots, ranging from 2 slots to 18 slots.

• System Bandwidth:

• Supports different system bandwidths, such as 2 GB/s, 8 GB/s, 24GB/s, etc.

• Slot Cooling Capacity:

• Provides different slot cooling capacities, such as 38 W, 58 W, 82W, etc.

• Power Supply Type:

• AC or DC.

• Clock Type:

• VCXO or OCXO.

• Please refer to the official NI product manual for specific product parameters.

Product Advantages

• High Performance:

• PXI Express chassis provides high-bandwidth, low-latency data transfer, suitable for high-performance test and measurement applications.

• Modularity and Flexibility:

• Users can select and configure modules as needed to build customized systems.

• Timing and Synchronization:

• Precise timing and synchronization capabilities for synchronizing multiple instrument modules.

• Ruggedness and Reliability:

• Rugged chassis design, suitable for industrial environments.

Precautions

• Correct Installation:

• Install and wire according to the requirements of the product manual.

• Cooling:

• Ensure sufficient ventilation space around the chassis to ensure cooling effectiveness.

• Electrostatic Protection:

• Take electrostatic protection measures when operating modules.

• Compatibility:

• Pay attention to the compatibility of modules and chassis.

Product Applications

• Automated Testing:

• Used in automated test systems for electronics, communications, aerospace, and other fields.

• Data Acquisition:

• Used for acquiring high-speed, high-precision data.

• Signal Processing:

• Used for real-time signal processing and analysis.

• Control Systems:

• Used to build high-performance control systems.
