Brand： Omron
Model number： G2A-432A-N
Colour：new
Warranty: 12 months
Lead Time：3-day working day
Country of origin: USA Price: Please contact us
Product weight：0.15kg
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
Description:
Highly Reliable, 4-pole Miniature Relay Ideal
for Sequence Control
• Card lift-off employed for greater life and stable quality.
• Long endurance and stable quality are assured by card lift-off
system.
• Mounting interchangeability with MY-series Relays.
• Operation indicator mechanism incorporated for at-a-glance
monitoring of ON/OFF operation. In addition, a built-in operation
indicator model is also included in this Relay Series.
Relays Other than Standard Models
Arc barrier equipped Built-in diode Built-in operation indicator
G2A-432AY G2A-432A-D G2A-432A-N
The arc barrier equipped model is
a relay designed to prevent arc
short-circuiting between phases
and can be used in a circuit which
has potential difference between
phases. The switching power of
such a circuit with potential difference
must be limited to less than
1/2 the rated load when using this
Relay.
The built-in diode model is a relay
which incorporates a diode for absorption
of the reverse voltage
that may be generated when the
coil is de-energized. Because the
release time of this model is longer
than the standard model, pay
adequate attention to this point in
designing a circuit. Also, pay attention
to the + polarity of the coil.
The reverse-breakdown voltage
of the diode is 1,000 V.
The built-in operation indicator
model has a newly added operation
indicator to the conventional
operation indication mechanism
and facilitates operation monitoring
without being affected by ambient
illumination.
With the -N model (rated at 16,
12, 24, and 48 VDC) and -N1
model rated at 6, 12, 24, 48, and
100 VDC), pay attention to the +
polarity of the coil.
