Omron H8PS-16BF Digital position indicator

OMRON H8PS-16BF Overview

The OMRON H8PS-16BF is a digital position indicator designed for precise display and control of position, angle, or length in various industrial applications. It features high resolution, versatility, and ease of operation.

Product Detailed Description

• Function:

• Receives pulse signals from encoders or other position sensors.

• Accurately displays the current position, angle, or length value in digital form with high precision.

• Provides preset functions for setting target positions or triggering control outputs.

• Supports various counting modes and input modes to suit different application needs.

• Features an alarm function that issues an alert when the actual position exceeds the preset range.

• Some models may have communication interfaces for easy integration with host computer systems.

• Features:

• 6-digit or 8-digit digital display (depending on the specific model).

• Multiple display modes (e.g., absolute position, incremental position, angle).

• Multiple input modes (e.g., single-phase input, quadrature phase input).

• Multiple counting modes (e.g., up counting, down counting, reversible counting).

• Preset function with the ability to set multiple target values.

• Alarm output function.

• Optional communication interfaces (e.g., RS-485).

• DIN rail mounting.

• High front panel protection rating.

Product Parameters

As the OMRON H8PS series has various models, parameters may differ. The following are typical parameters for the H8PS-16BF. Always refer to the official datasheet for the specific model:

• Display Digits:

• 6 digits

• Input Signals:

• Pulse input (single-phase or quadrature phase)

• Voltage input: 5 V DC, 12 V DC, 24 V DC (depending on wiring)

• Maximum Counting Frequency:

• Typically high, e.g., 50 kHz or higher

• Counting Modes:

• Up counting, down counting, reversible counting

• Input Modes:

• Single-phase (1x, 2x)

• Quadrature phase (1x, 2x, 4x)

• Preset Outputs:

• 2 points or more (relay or transistor output, depending on the model)

• Alarm Outputs:

• 1 point or more (relay or transistor output, depending on the model)

• Power Supply Voltage:

• 100-240 V AC 50/60 Hz

• 24 V DC (some models)

• Power Consumption:

• Approx. 5 VA or less

• Mounting Method:

• DIN rail mounting

• Front Panel Protection Rating:

• IP66

• Ambient Temperature:

• Operating temperature: -10 °C to +55 °C

• Storage temperature: -25 °C to +65 °C

Product Advantages

• High-Precision Display:

• Accurately displays position, angle, or length values.

• Versatility:

• Supports multiple input modes, counting modes, and display modes, suitable for a wide range of applications.

• Easy Operation:

• Front panel keys and clear display make it easy for users to set parameters and operate.

• High Reliability:

• Industrial-grade design ensures stable operation in harsh environments.

• Preset and Alarm Functions:

• Facilitates automated control and fault warning.

• Easy Installation:

• DIN rail mounting saves space and simplifies installation.

Precautions

• Correct Wiring:

• Connect power, input signals, and output signals correctly according to the wiring diagram.

• Ensure the voltage and frequency of the input signals meet the product specifications.

• Parameter Settings:

• Set the counting mode, input mode, preset values, and alarm values correctly according to specific application needs.

• Carefully read the product manual to understand the meaning and setting methods of each parameter.

• Environmental Conditions:

• Avoid using the product in environments exceeding its operating temperature and humidity ranges.

• Avoid strong vibrations and shocks.

• Input Signal Quality:

• Ensure the stability and accuracy of the input signals to avoid interference.

• Safe Use:

• Do not use in flammable or explosive hazardous areas.

Product Applications

The OMRON H8PS-16BF or similar digital position indicators are widely used in various industrial fields, including but not limited to:

• Machine Tools:

• Display of machine tool slide position.

• Control of tool position.

• Textile Machinery:

• Control of yarn length.

• Display of winding position.

• Packaging Machinery:

• Control of film length.

• Control of label position.

• Printing Machinery:

• Control of paper position.

• Registration control.

• Woodworking Machinery:

• Display of board cutting length.

• Wire and Cable Equipment:

• Counting of cable length.

• Automated Assembly Lines:

• Display and control of component position.
