AUTOMATION DIREC F2-08AD-2 ControlNet

Product Description

The Automation Direct 16-Channel Analog Input Module is a versatile and high-performance I/O module designed for integration with Automation Direct PLC systems, including the DirectLOGIC DL405 and Productivity3000 series. It provides reliable and precise conversion of analog signals (voltage or current) into digital values for real-time monitoring and control in industrial automation environments. This module is ideal for applications requiring multiple analog signal inputs with high resolution and fast response times.

Product Specifications

Parameter	Description
Number of Channels	16 single-ended or 8 differential channels (depending on model)
Input Signal Types	Voltage (0–10V, ±10V, 0–5V, ±5V), Current (4–20mA, 0–20mA)
Resolution	12-bit or 16-bit (model-dependent)
Conversion Time	Typically < 1 ms per channel
Accuracy	±0.1% of full scale (typical)
Isolation	Channel-to-channel and channel-to-ground isolation (varies by model)
Communication Interface	Backplane bus compatible with supported PLC systems
Power Requirements	24V DC (from PLC base or external supply)
Operating Temperature	0°C to 60°C (32°F to 140°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Humidity	5% to 95% (non-condensing)
Certifications	UL, CE, RoHS compliant

Product Advantages

High Channel Density: 16 inputs in a single module reduce space requirements and cost.
Flexible Input Support: Compatible with a wide range of industrial voltage and current signals.
High Resolution and Accuracy: Ensures precise measurement for critical control tasks.
Robust Isolation: Protects against noise and voltage spikes in harsh industrial environments.
Ease of Integration: Fully compatible with Automation Direct PLCs and programming software.
Diagnostics and Monitoring: Built-in status indicators and diagnostics for troubleshooting.
Cost-Effective: Provides a low-cost-per-channel solution compared to competitors.

Precautions

Wiring Guidelines: Use shielded twisted-pair cables for analog signals to minimize noise interference.
Grounding: Ensure proper grounding to avoid ground loops and signal distortion.
Configuration: Properly configure input types (voltage/current) and ranges in the PLC programming software.
Overvoltage Protection: Avoid exceeding the maximum input voltage/current ratings to prevent damage.
Environmental Conditions: Do not operate beyond the specified temperature and humidity limits.
Firmware Compatibility: Ensure the PLC firmware supports the analog module version being used.

Product Applications

Process Control: Monitoring temperature, pressure, flow, and level sensors in manufacturing plants.
Building Automation: HVAC systems, lighting control, and energy management.
Water/Wastewater Management: Monitoring pump speeds, valve positions, and chemical dosing.
Factory Automation: Integration with robotic systems, conveyors, and assembly lines.
Test and Measurement: Data acquisition for R&D, product testing, and quality assurance.
Energy Systems: Solar inverters, battery management, and power monitoring.
Material Handling: Load cells, position feedback, and motor current monitoring.
