AutomationDirect C0-00DD1-D CPU Module

Brand:AutomationDirect

Model number: C0-00DD1-D

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.25kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

AutomationDirect C0-00DD1-D CPU Module

INQUIRE NOW

Products Name: AutomationDirect C0-00DD1-D CPU Module

PRODUCT DESCRIPTION

AutomationDirect C0-00DD1-D Overview

The AutomationDirect C0-00DD1-D is a DC digital output module belonging to the CLICK series of PLCs (Programmable Logic Controllers). The CLICK series is known for its ease of use, compact design, and cost-effectiveness, making it suitable for various small automation applications. The C0-00DD1-D is a digital output module within this series.

Product Detailed Description

  • Function:

    • Provides 8 sinking (NPN) DC digital output points.

    • Used to control external DC loads such as relays, indicator lights, small DC motors, etc.

    • Receives control signals from the PLC CPU module and switches the external devices connected to its outputs ON or OFF based on these signals.

  • Features:

    • 8 sinking (NPN) digital outputs.

    • Each output point is rated for 0.5 A.

    • Outputs have short-circuit protection.

    • Utilizes removable terminal blocks for easy wiring and maintenance.

    • Compact design saves installation space.

    • Requires use with a CLICK series PLC CPU module.

Product Parameters

  • Type:

    • DC Digital Output Module.

  • Number of Output Points:

    • 8 points.

  • Output Type:

    • Sinking (NPN).

  • Maximum Current per Output Point:

    • 0.5 A.

  • Maximum Current per Common:

    • 2.0 A.

  • Output Voltage Range:

    • 24 VDC (permissible range 20.4 - 26.4 VDC).

  • Surge Current Withstand:

    • Depends on the load characteristics.

  • Short-Circuit Protection:

    • Electronic short-circuit protection on each output point.

  • Isolation:

    • No isolation.

  • Wiring Method:

    • Removable screw terminals.

  • Module Dimensions (W x H x D):

    • Refer to the CLICK series PLC dimensional specifications.

  • Weight:

    • Refer to the CLICK series PLC weight specifications.

  • Operating Temperature:

    • 0°C to 50°C (32°F to 122°F).

  • Storage Temperature:

    • -20°C to 70°C (-4°F to 158°F).

  • Humidity:

Product Advantages

  • Cost-Effective:

    • The CLICK series PLC is known for its high value for the price.

  • Easy to Use:

    • The programming software for CLICK PLCs is intuitive.

    • Removable terminals simplify wiring.

  • Compact Design:

    • Saves control panel space.

  • Reliability:

    • AutomationDirect is a reputable supplier of industrial automation products.

  • Short-Circuit Protection:

    • Protects the output circuits and connected loads.

Precautions

  • Correct Wiring:

    • Ensure that power and loads are wired correctly according to the wiring diagram.

    • Verify that the power supply voltage is within the module's allowable range.

    • Do not exceed the rated current per output point and per common.

  • Sinking Output:

    • This module has sinking (NPN) outputs; ensure that the connected loads are compatible with this output type.

  • No Isolation:

    • There is no electrical isolation between the inputs and outputs.

  • Environmental Conditions:

    • Ensure that the operating environment temperature and humidity are within the module's allowable range.

    • Avoid use in environments with corrosive gases or excessive dust.

  • Use with CPU Module:

    • This is an output module and requires a CLICK series PLC CPU module to form a complete control system.

Product Applications

The AutomationDirect C0-00DD1-D digital output module is commonly used in various small automation projects requiring the control of DC devices, such as:

  • Simple Machine Control:

    • Controlling the start/stop of small motors.

    • Controlling the movement of cylinders or valves.

  • Indication and Alarms:

    • Driving indicator lights to display equipment status.

    • Triggering alarm signals.

  • Small Conveyor Systems:

    • Controlling the start/stop of conveyor belts.

  • Lighting Control:

    • Controlling DC lighting equipment.

  • DIY and Educational Projects:

    • Used for automation-related learning and experiments.

AutomationDirect C0-00DD1-D
