AutomationDirect C0-08NE3 CPU 单元

AutomationDirect C0-08NE3 Overview

The AutomationDirect C0-08NE3 is a CPU unit belonging to the CLICK series of Programmable Logic Controllers (PLCs). CLICK PLCs are designed to provide easy-to-use, cost-effective control solutions for a variety of small automation applications. The C0-08NE3 model features integrated input/output (I/O) points.

Product Detailed Description

• Function:

• Executes user-written control programs.

• Monitors input signals and controls output signals based on program logic.

• Provides real-time control for various automation tasks.

• Supports a variety of programming instructions, including logic, counters, timers, etc.

• Allows program download and monitoring via the programming port.

• Features:

• Compact design to save installation space.

• Integrated 8 digital input points (24 VDC sink/source).

• Integrated 6 digital output points (24 VDC source).

• Integrated RS-232 and RS-485 communication ports.

• Supports CLICK series expansion modules for increasing I/O point count.

• Programmed using the free CLICK programming software.

Product Parameters

• CPU Type: CLICK Series CPU

• Integrated Input Points: 8 points (24 VDC sink/source)

• Integrated Output Points: 6 points (24 VDC source, sinking)

• Output Type: Transistor (Source)

• Communication Ports:

• 1 x RS-232 Programming Port (RJ12)

• 1 x RS-485 Communication Port (Terminal Block)

• Program Memory Capacity: 2048 Steps

• Data Memory Capacity: 2048 Words

• Timers: 256 (T0-T255), Resolution 1 ms to 9999 ms

• Counters: 256 (C0-C255), 16-bit Up/Down Counting

• Power Supply: 24 VDC

• Current Consumption: Typ. 60 mA

• Fuse: External 0.5A, 250V fast-acting fuse required

• Operating Temperature: 0°C to 55°C (32°F to 131°F)

• Storage Temperature: -20°C to 70°C (-4°F to 158°F)

• Humidity: 5% to 95% (non-condensing)

• Mounting: DIN Rail

• Dimensions: 90 mm (H) x 72 mm (W) x 60 mm (D)

• Certifications: CE, UL

Product Advantages

• Easy to Use: Intuitive and easy-to-learn CLICK programming software.

• Cost-Effective: Provides a high-value solution for small applications.

• Compact Design: Saves control panel space.

• Integrated I/O: Reduces the need for additional hardware, lowering costs.

• Communication Capabilities: Integrated RS-232 and RS-485 ports for easy communication with other devices.

• Scalability: Supports expansion modules to increase I/O point count as needed.

• Reliability: Industrial-grade design ensures reliable operation in industrial environments.

Precautions

• Correct Wiring: Connect input, output, and power lines correctly according to the wiring diagram.

• Power Requirements: Use a 24 VDC power supply that meets the specifications.

• Current Limits: Do not exceed the maximum current limit for each output point.

• Fuse Protection: Ensure proper fuse protection is provided in the external power circuit.

• Environmental Conditions: Use within the specified operating temperature and humidity ranges.

• ESD Protection: Take precautions against electrostatic discharge (ESD) when handling the PLC.

• Software Compatibility: Use compatible CLICK programming software for programming and monitoring.

Product Applications

The AutomationDirect C0-08NE3 PLC is suitable for various small automation applications, including but not limited to:

• Small Machine Control: E.g., simple packaging machines, conveyor control.

• Process Control: E.g., temperature control, level control.

• Building Automation: E.g., lighting control, small control for HVAC systems.

• Material Handling: E.g., simple sorting system control.

• OEM Equipment: Integrated as the control core in small automated equipment.

• Education and Training: Used for automation teaching and experiments.
