AutomationDirect C0-08TD1 CPU Module

Brand:AutomationDirect

Model number:C0-08TD1

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.25kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

AutomationDirect C0-08TD1 CPU Module

INQUIRE NOW

Products Name: AutomationDirect C0-08TD1 CPU Module

PRODUCT DESCRIPTION

AutomationDirect C0-08TD1 Overview

The AutomationDirect C0-08TD1 is a Programmable Logic Controller (PLC) CPU unit belonging to their CLICK series. CLICK PLCs are known for their ease of use, compact size, and cost-effectiveness, making them suitable for various small automation applications. The C0-08TD1 model features digital inputs and outputs, along with integrated terminal blocks for easy wiring.

Product Detailed Description

  • Function:

    • Executes user-written logic programs to control connected input and output devices.

    • Provides reading of digital input signals and control of digital output signals.

    • Supports basic logic functions such as timers, counters, relays, and data handling.

    • Program creation, download, and monitoring are done through programming software.

  • Features:

    • Compact design, saving installation space.

    • Integrated 8 digital I/O points (4 inputs, 4 outputs).

    • Utilizes detachable terminal blocks for easy wiring and maintenance.

    • Built-in RS-232 communication port for programming and communication.

    • Optional expansion modules available to increase I/O count and communication capabilities.

    • Programmed using free, easy-to-learn CLICK programming software.

    • LED indicators display CPU status and I/O point status for easy diagnostics.

Product Parameters

  • CPU Type:

    • CLICK Series CPU Unit

  • I/O Points:

    • 4 x 24 VDC Sinking/Sourcing Inputs

    • 4 x 24 VDC Sinking Transistor Outputs (0.5 A/point)

    • 8 Integrated Digital I/O Points

  • Power Supply:

    • 24 VDC

  • Program Memory:

    • 2048 Steps

  • Data Memory:

    • 2048 Words

  • Communication Port:

    • 1 x RS-232 Programming/Communication Port (RJ12 Connector)

  • Scan Time:

    • Typically 2 to 10 ms

  • Mounting:

    • DIN Rail Mounting

  • Dimensions:

    • 90 mm (H) x 75 mm (W) x 60 mm (D)

  • Operating Temperature:

    • 0 °C to +55 °C

  • Certifications:

    • CE, UL

  • For more detailed parameters, please refer to the official datasheet for the AutomationDirect C0-08TD1.

Product Advantages

  • Easy to Use:

    • The CLICK series is known for its simple and easy-to-learn programming software and hardware design.

  • Cost-Effective:

    • The C0-08TD1 offers an affordable solution for small automation applications.

  • Compact Design:

    • Saves installation space, suitable for applications with limited space.

  • Integrated I/O:

    • The integrated 8 digital I/O points are suitable for simple control tasks.

  • Convenient Wiring:

    • Detachable terminal blocks simplify wiring and maintenance.

  • Expandability:

    • Supports expansion modules to increase the I/O count as needed.

  • Reliability:

    • AutomationDirect products are known for their reliability.

Precautions

  • Correct Wiring:

    • Connect input and output devices correctly according to the wiring diagram, paying attention to the input and output types (sinking/sourcing).

  • Power Requirements:

    • Use a 24 VDC power supply that meets the specifications.

  • Programming Software:

    • Use the free CLICK programming software for program creation and download.

  • Current Limitation:

    • Do not exceed the rated output current per channel (0.5 A).

  • Environmental Conditions:

    • Ensure the operating environment temperature is within the allowable range, and avoid humidity and corrosive gases.

  • ESD Protection:

    • Take precautions against electrostatic discharge (ESD) when handling and wiring.

  • Safety Measures:

    • Implement additional safety measures in applications involving personnel safety.

Product Applications

  • Small Machine Control:

    • Control of simple automated equipment.

  • Conveyor System Control:

    • Start/stop control of small conveyor belts.

  • Lighting Control:

    • Simple industrial lighting control.

  • Pump and Fan Control:

    • Simple on/off control.

  • Access Control Systems:

    • Simple access control logic.

  • Educational Applications:

    • Used for teaching automation and PLC programming.

  • Replacement of Relay Logic:

    • Replacing traditional relay control circuits.
