AutomationDirect C0-08TR CPU Unit

AutomationDirect C0-08TR Overview

The AutomationDirect C0-08TR is a CPU unit belonging to the CLICK series of Programmable Logic Controllers (PLCs). It is a compact PLC with integrated input and output (I/O) points, and functionality for controlling various automation tasks. The "TR" in the model typically indicates transistor outputs.

Product Detailed Description

• Function:

• Executes user-written control programs.

• Monitors input signals and controls output devices based on program logic.

• Provides timers, counters, relays, data handling, and other logic functions.

• Communicates with programming software via the programming port.

• Features:

• Compact design, saving installation space.

• Integrated 8 I/O points: 4 24VDC inputs and 4 24VDC transistor sourcing outputs.

• 8K step program memory.

• 8K bytes data memory.

• One RS-232 or RS-485 communication port (selectable via jumper).

• Supports High-Speed Counter (HSC) function.

• Supports Pulse Train Output (PTO) function.

• Programmed using the free CLICK PLC programming software.

• DIN rail mounting.

Product Parameters

• CPU Type: CLICK Series

• Number of I/O Points: 8 points (4 Input / 4 Output)

• Input Type: 24VDC Sink/Source (selectable via wiring)

• Output Type: 24VDC Transistor Sourcing

• Output Current: Max. 0.5A per point

• Program Memory: 8K Steps

• Data Memory: 8K Bytes

• Communication Port: 1 RS-232 or RS-485 (selectable via jumper)

• High-Speed Counter (HSC): 1 channel, max. 10 kHz

• Pulse Train Output (PTO): 1 channel, max. 10 kHz

• Scan Time: Typical 2-8 ms

• Supply Voltage: 20.4 - 28.8 VDC

• Power Consumption: Typical 3W

• Operating Temperature: 0°C to 55°C (32°F to 131°F)

• Storage Temperature: -20°C to 70°C (-4°F to 158°F)

• Humidity: 5% to 95% (non-condensing)

• Protection Rating: IP20

• Mounting: DIN Rail

• Dimensions: 90 mm (H) x 75 mm (D) x 30 mm (W)

Product Advantages

• Cost-Effective: Provides an affordable automation control solution.

• Easy to Use: The CLICK PLC programming software is intuitive and easy to learn.

• Compact Design: Saves control panel space.

• Integrated I/O: Reduces the need for additional I/O modules, lowering cost and complexity.

• Flexible Communication: Selectable RS-232 or RS-485 communication.

• High-Speed Counter and Pulse Output: Suitable for applications requiring high-speed event counting and stepper/servo control.

• Reliability: Industrial-grade design for reliable operation in industrial environments.

Precautions

• Correct Wiring: Connect inputs, outputs, and power supply according to the wiring diagram.

• Power Requirements: Use a 24VDC power supply that meets the specifications.

• Output Current Limitation: Do not exceed the maximum output current of 0.5A per point.

• Environmental Conditions: Ensure the operating environment temperature and humidity are within the allowable range.

• ESD Protection: Take precautions against electrostatic discharge (ESD) when handling the PLC.

• Programming Software: Use the free CLICK PLC programming software for programming and configuration.

• Communication Settings: Configure the jumpers and software settings for the communication port (RS-232 or RS-485) correctly.

Product Applications

The AutomationDirect C0-08TR PLC is suitable for various small automation applications, including but not limited to:

• Simple Machine Control: Controlling the start, stop, and sequential operation of small mechanical equipment.

• Material Handling: Controlling small conveyors and sorting systems.

• Lighting Control: Timing and logic control of industrial or commercial lighting systems.

• Heating, Ventilation, and Air Conditioning (HVAC): Controlling the operation of small HVAC units.

• Pump and Fan Control: Simple start/stop and speed control.

• Small Process Control: Basic temperature, pressure, or level control.

• Education and Training: Used for teaching automation control principles.
