AutomationDirect D2-08NA-1 CPU module

AutomationDirect D2-08NA-1 Overview

The AutomationDirect D2-08NA-1 is a CPU module belonging to the popular DL205 series of PLCs. It is a compact and versatile controller suitable for a variety of industrial automation applications.

Product Detailed Description

• Function:

• Executes control logic based on user-programmed instructions.

• Provides input and output (I/O) capabilities through integrated points and expansion modules.

• Supports various programming languages, primarily ladder logic.

• Offers communication ports for interfacing with other devices and systems.

• Features:

• Compact and cost-effective CPU.

• Integrated I/O points: 8 inputs (24 VDC sink/source) and 6 outputs (24 VDC sink).

• Expandable I/O capabilities using DL205 series modules.

• Built-in RS-232 and RS-485 communication ports.

• Real-time clock/calendar.

• Non-volatile memory for program and data retention.

• Status indicators for easy troubleshooting.

• Compatible with DirectSOFT programming software.

Product Parameters

• CPU Type: DL205 Series

• Integrated Inputs: 8 points, 24 VDC Sink/Source

• Integrated Outputs: 6 points, 24 VDC Sink

• Expansion I/O: Up to 7 additional DL205 series I/O modules

• Program Memory: 7.8K words (EEPROM)

• Data Memory (V-Memory): 5,120 words (EEPROM)

• Communication Ports:

• Port 1 (CPU): RS-232, supports DirectNET/K-Sequence, Modbus RTU (Master/Slave), ASCII In/Out

• Port 2 (Terminal Block): RS-485, supports DirectNET/K-Sequence, Modbus RTU (Master/Slave)

• Scan Time: Typically 0.37 ms per K of ladder logic

• Real-Time Clock/Calendar: Yes

• Power Requirements: 24 VDC

• Current Consumption: 100 mA @ 24 VDC (CPU only)

• Operating Temperature: 0°C to 55°C (32°F to 131°F)

• Storage Temperature: -20°C to 70°C (-4°F to 158°F)

• Humidity: 5% to 95% non-condensing

• Dimensions: Compact size, refer to the DL205 Hardware User Manual for specific dimensions.

• Weight: Refer to the DL205 Hardware User Manual for specific weight.

• Certifications: UL, cUL, CE

Product Advantages

• Cost-Effective: Provides a good balance of features and performance at an affordable price.

• Compact Size: Suitable for applications with limited space.

• Integrated I/O: Offers basic I/O capabilities without requiring immediate expansion.

• Expandability: Allows for future system growth by adding more I/O modules.

• Versatile Communication: Built-in RS-232 and RS-485 ports support common industrial protocols.

• Real-Time Clock: Enables time-based control and data logging.

• Non-Volatile Memory: Retains program and data even during power loss.

• Easy Programming: Compatible with the user-friendly DirectSOFT programming software.

• Reliable Performance: Proven track record in various industrial applications.

Precautions

• Correct Wiring: Ensure proper wiring of input and output points according to the wiring diagrams in the DL205 Hardware User Manual.

• Power Supply: Use a stable and correctly rated 24 VDC power supply.

• Environmental Conditions: Operate within the specified temperature and humidity ranges. Avoid exposure to excessive dust, vibration, and corrosive substances.

• Grounding: Ensure proper grounding of the PLC system to prevent electrical noise and ensure safety.

• I/O Module Compatibility: Only use I/O modules from the AutomationDirect DL205 series for expansion.

• Programming Software: Use the appropriate version of DirectSOFT programming software for configuration and programming.

• Firmware Updates: Follow AutomationDirect's recommendations for firmware updates.

• Safety Procedures: Adhere to all relevant safety procedures when installing, operating, and maintaining the PLC system.

Product Applications

The AutomationDirect D2-08NA-1 PLC is suitable for a wide range of industrial automation applications, including:

• Machine Control: Controlling various types of machinery, such as packaging machines, conveyors, and small automated systems.

• Material Handling: Automation of material handling processes.

• Process Control: Basic process control applications.

• Building Automation: Controlling lighting, HVAC, and other building systems.

• Data Acquisition: Collecting data from sensors and other devices.

• Small to Medium-Sized Automation Projects: Providing a cost-effective control solution for various automation tasks.

• Educational Purposes: Used in training and educational settings for learning PLC programming and control principles.
