AUTOMATIONDIRECTS EA9-T6CL touchscreen

AutomationDirects EA9-T6CL Overview

The AutomationDirects EA9-T6CL is a C-more® touchscreen HMI (Human Machine Interface) from the EA9 series. It provides a 6-inch color touchscreen for visualization and control of machines and processes in industrial automation applications.

Product Detailed Description

• Function:

• Provides a visual interface for machines and processes.

• Allows operators to monitor and control via the touchscreen.

• Communicates with PLCs (Programmable Logic Controllers) and other automation devices via Ethernet, serial, and other interfaces.

• Supports features such as animation, trend graphs, alarms, recipes, data logging, and scripting.

• Offers a clear and easy-to-read color graphical display.

• Rugged industrial design suitable for various industrial environments.

• Features:

• 6-inch TFT LCD color touchscreen with 800 x 480 pixel resolution.

• LED backlight with adjustable brightness.

• Two Ethernet ports (10/100Base-T).

• Two USB ports (1 USB Type A Host, 1 USB Type B Device).

• Multiple serial communication ports (RS-232, RS-422/485).

• Integrated C-more programming software (free download).

• 800 MHz CPU for fast performance.

• 4GB of onboard memory.

• Supports various communication protocols such as Modbus TCP/IP, EtherNet/IP, Modbus RTU.

Product Parameters

• Display:

• Size: 6 inches

• Type: TFT LCD Color Touchscreen

• Resolution: 800 x 480 pixels

• Brightness: 300 cd/m² (typical)

• Backlight: LED

• Touch Type: Analog Resistive

• Power Supply:

• Voltage: 24 VDC (20.4 - 28.8 VDC)

• Power Consumption: 7.2 W max

• Interfaces:

• Ethernet: 2 x RJ45 (10/100Base-T)

• USB: 1 x USB A (Host), 1 x USB B (Device)

• Serial: 1 x RS-232, 1 x RS-422/485

• Memory:

• Onboard: 4 GB

• Processor:

• 800 MHz CPU

• Degree of Protection:

• Front Panel: IP65F (Equivalent to NEMA 4X Indoor Use)

• Rear Panel: IP20

• Operating Temperature:

• 0°C to 50°C (32°F to 122°F)

• Storage Temperature:

• -20°C to 60°C (-4°F to 140°F)

• Dimensions ¹ (W x H x D):

• 186.5 mm x 142 mm x 41.5 mm

• Cutout Dimensions (W x H):

• 172 mm x 128 mm

• Weight:

• Approx. 0.7 kg (1.54 lbs)

• Certifications:

• CE, cULus

Product Advantages

• Cost-Effective:

• Offers powerful features and performance at a competitive price.

• Easy to Use:

• Intuitive C-more programming software that is easy to learn and use.

• User-friendly interface design.

• Powerful Connectivity:

• Dual Ethernet ports and multiple serial ports for easy connection to various devices.

• Supports a wide range of industrial communication protocols.

• High Performance:

• 800 MHz CPU and ample memory ensure smooth operation and fast response.

• Rugged and Durable:

• Industrial-grade design with a high front panel protection rating suitable for industrial environments.

• Rich Functionality:

• Supports various functions such as animation, trend graphs, alarms, recipes, data logging, and scripting to meet diverse application needs.

• Free Programming Software:

• C-more programming software is available for free download, reducing overall cost.

Precautions

• Correct Installation:

• Follow AutomationDirect's installation guidelines, ensuring the panel is securely mounted and properly grounded.

• Power Requirements:

• Use a 24 VDC power supply that meets the specifications.

• Environmental Conditions:

• Ensure the operating environment temperature and humidity are within the permissible range.

• Avoid strong vibrations and shocks.

• Programming Software:

• Requires C-more programming software for project creation and configuration.

• Cable Connections:

• Use appropriate cables to connect the HMI panel to PLCs and other devices, and ensure reliable connections.

• ESD Protection:

• Observe electrostatic discharge (ESD) precautions when handling the HMI panel.

Product Applications

The AutomationDirects EA9-T6CL HMI touchscreen panel is widely used in various industrial automation fields, including but not limited to:

• Machine Control:

• As an operator interface for various industrial machinery.

• Process Control:

• Used for monitoring and controlling industrial processes.

• Packaging Machinery:

• Controlling and visualizing packaging processes.

• Food and Beverage Industry:

• Operating and monitoring food and beverage production equipment.

• Pharmaceutical Industry:

• Monitoring and controlling pharmaceutical manufacturing processes.

• Water Treatment Industry:

• Monitoring and controlling water treatment equipment.

• Building Automation:

• Monitoring and controlling HVAC, lighting, and other systems.
