Berger WDP3-014.0801 Stepper Motor

Berger Lahr WDP3-014.0801 Overview

The Berger Lahr WDP3-014.0801 is an intelligent, three-phase stepper motor drive. It is designed to control Berger Lahr or other compatible three-phase stepper motors, providing precise position and velocity control. This drive is commonly used in various automation applications.

Product Detailed Description

• Function:

• Controls the stepping and direction of three-phase stepper motors.

• Offers various microstepping modes to improve resolution and smoothness.

• Supports closed-loop control (may require encoder feedback, depending on the configuration and motor).

• Features programmable parameters to optimize motor performance and adapt to different application requirements.

• Integrated protection functions such as overcurrent, overvoltage, and undervoltage protection.

• May support multiple control interfaces such as pulse/direction, analog, or fieldbus (depending on the specific model variant).

• Features:

• Intelligent drive with an onboard microprocessor.

• High precision and high reliability.

• Compact design.

• Easy to configure and commission.

Product Parameters

As the model number is very specific and may have various configurations and variants, the following are typical parameters that drives in this series might have. Always refer to the official datasheet for the specific WDP3-014.0801 model:

• Motor Type:

• Three-phase stepper motors.

• Current Range:

• Possibly up to 14 A (RMS), depending on the model.

• Voltage Range:

• Possibly up to 80 V DC, depending on the model.

• Microstepping Resolution:

• Programmable, typically supports various microstepping modes (e.g., full step, half step, microsteps).

• Control Interface:

• May support Pulse/Direction, Analog, CANopen, or other fieldbus interfaces (depending on the specific model variant).

• Feedback:

• May support encoder feedback for closed-loop control (depending on the model).

• Protection Functions:

• Overcurrent Protection.

• Overvoltage Protection.

• Undervoltage Protection.

• Overtemperature Protection.

• Ambient Temperature:

• Operating temperature range typically 0 °C to +45 °C or similar.

• Protection Class:

• Possibly IP20 or higher.

• Dimensions and Mounting:

• DIN rail mounting or panel mounting.

Product Advantages

• Precise Control:

• Provides precise position and velocity control, suitable for high-accuracy applications.

• Smooth Operation:

• Microstepping modes reduce vibration and noise, resulting in smoother motor operation.

• High Reliability:

• Berger Lahr (now part of Schneider Electric) is a well-known manufacturer of motors and drives with reliable product quality.

• Flexibility:

• Programmable parameters and multiple control interfaces make it suitable for different application requirements.

• Integrated Protection:

• Built-in protection functions enhance system safety and reliability.

• Closed-Loop Capability (if supported):

• Enables more accurate control and higher torque through encoder feedback.

Precautions

• Correct Selection:

• Select the appropriate drive model based on the specifications (current, voltage) of the three-phase stepper motor being used and the application requirements.

• Correct Wiring:

• Connect the motor, power supply, and control signals correctly according to the wiring diagram in the product manual.

• Power Requirements:

• Use a power supply that meets the drive's specifications.

• Environmental Conditions:

• Ensure the operating environment temperature is within the permissible range and avoid humidity and dust.

• Parameter Configuration:

• Use the appropriate software or interface to correctly configure the drive's parameters to optimize motor performance.

• Overcurrent Protection Setting:

• Set the overcurrent protection parameters correctly based on the motor's rated current.

• Heat Dissipation:

• Provide adequate heat dissipation if necessary to prevent the drive from overheating.

Product Applications

• Automation Technology:

• Precision positioning systems.

• Robotics.

• Material handling systems.

• Semiconductor Manufacturing:

• Wafer processing equipment.

• Printing Machinery:

• Precise paper and ink control.

• Textile Machinery:

• Yarn control and positioning.

• Medical Equipment:

• Precise motion control applications.

• Packaging Machinery:

• Precise product positioning and filling.
