Bihl+Wiedemann BWU2234 Overview
The Bihl+Wiedemann BWU2234 is an AS-Interface safety input module. It is designed to connect standard binary sensors and actuators to an AS-Interface safety network, especially suitable for automation applications requiring safety functions.
Product Detailed Description
Function:
The BWU2234 allows the connection of up to four standard binary input devices (such as safety sensors, safety switches) to an AS-Interface safety network.
It converts these input signals into the AS-Interface safety protocol so that a safety controller can process them.
The module has integrated safety functions and complies with relevant safety standards (e.g., EN ISO 13849-1).
It typically features LED indicators for power supply, AS-Interface communication, and input status.
The module is powered via the AS-Interface bus.
Features:
Connection of 4 safety inputs.
Compact design for DIN rail mounting.
Integrated AS-Interface safety communication.
Complies with safety standards.
LED status indication.
Product Parameters
As specific models may have slight variations, please always refer to the official datasheet for the Bihl+Wiedemann BWU2234. Here are some typical parameters for AS-Interface safety input modules for reference:
AS-Interface Version:
Typically supports AS-Interface Safety at Work (SaW) version.
Number of Input Channels:
4 safety inputs.
Input Type:
Suitable for normally open (NO) and normally closed (NC) contacts.
Input Voltage:
Typically supplied by the AS-Interface bus (typical value 24 V DC).
AS-Interface Current Consumption:
Varies depending on the specific model.
Safety Category:
Complies with relevant safety standards, e.g., EN ISO 13849-1 (depending on the specific configuration and system).
Connection Method:
Typically uses screw terminals or spring terminals.
Protection Degree:
Typically IP20.
Ambient Temperature:
Operating temperature range typically from -25 °C to +70 °C.
Dimensions (W x H x D):
Please refer to the datasheet for specific dimensions.
Mounting Method:
DIN rail mounting.
Product Advantages
Integrated Safety Functions:
Specifically designed for safety applications, simplifying the design of safety circuits.
Easy Integration:
As part of the AS-Interface network, it is easy to integrate with other AS-Interface devices.
Wiring Savings:
Reduces traditional point-to-point wiring by using AS-Interface bus technology.
Flexible Expandability:
Additional safety input points can be easily added as needed.
Diagnostic Functions:
LED indicators typically provide diagnostic information on power, communication, and input status.
Compact Design:
Saves space in the control cabinet.
Precautions
Correct Installation:
Follow Bihl+Wiedemann's installation guidelines, ensuring the module is correctly mounted on the DIN rail and securely connected.
AS-Interface Network:
This module needs to be connected to the correct AS-Interface safety network to function.
Power Requirements:
Ensure the AS-Interface power supply meets the system requirements.
Safety Wiring:
The wiring of safety input devices must comply with relevant safety standards and the module's manual.
Parameter Configuration:
It may be necessary to configure the module parameters using an AS-Interface configuration tool.
Environmental Conditions:
Ensure the operating environment temperature is within the permissible range.
Regular Inspection:
Regularly check the module's connections and status indicators to ensure proper operation.
Product Applications
Machine Safety:
Connecting safety sensors, safety door switches, emergency stop buttons, etc.
Automation Technology:
Integrating safety input signals in automation systems.
Conveyor Technology:
Monitoring safety devices on conveyor belts.
Packaging Machinery:
Connecting safety switches and sensors on packaging machines.
**Any industrial application requiring AS-Interface safety inputs.
