Bihl+Wiedemann BWU2729 Overview
The Bihl+Wiedemann BWU2729 is an AS-Interface safety monitor with 2 safe outputs. It is used to monitor safety-related signals in an AS-Interface network and control safe outputs according to the configured safety logic.
Product Detailed Description
Function:
Monitors safety input signals in the AS-Interface network (e.g., from safety sensors, emergency stop buttons, safety gate switches).
Executes configured safety functions (e.g., emergency stop, safety gate interlock, two-hand control).
Controls 2 safe outputs (e.g., for switching off drives, activating safety brakes).
Supports the AS-i Safety at Work specification.
Configuration and diagnostics via the AS-i bus.
Integrated AS-i power supply.
Features:
Compact design for easy installation in control cabinets.
Monitoring of up to 31 safety slaves.
Configurable safety logic.
LED indicators for status and fault diagnostics.
Configuration via AS-i Safety Monitor software.
Product Parameters
AS-Interface Specification:
AS-i Safety at Work (version may vary depending on the specific model)
Safety Inputs:
Receives signals from safety slaves via the AS-i bus
Supports up to 31 safety slaves
Safety Outputs:
Semiconductor outputs (depending on the specific model)
Relay outputs (depending on the specific model)
2 safe outputs, e.g.:
Output characteristics (voltage, current) vary depending on the specific model, please refer to the datasheet.
AS-i Power Supply:
Integrated, provides power for the AS-i network
Output current varies depending on the specific model, please refer to the datasheet.
Configuration Interface:
Via the AS-i bus
Diagnostic Indicators:
LEDs indicate power, AS-i communication, safety status, and faults
Protection Class:
IP20 (may vary depending on the specific model)
Ambient Temperature:
Operating temperature range varies depending on the specific model, please refer to the datasheet.
Connection:
AS-i cable terminals
Power supply and I/O terminals (depending on the specific model)
Dimensions:
Dimensions vary depending on the specific model, please refer to the datasheet.
Certifications:
Complies with relevant safety standards (e.g., EN ISO 13849-1, IEC 61508)
Product Advantages
Integrated Safety Solution:
Combines safety monitoring and AS-i power supply in one compact device.
Simplified Wiring:
Reduces wiring effort for safety sensors by using the AS-i bus.
Flexible Safety Logic:
Safety functions can be configured via software to adapt to different application requirements.
Efficient Diagnostics:
LED indicators and software diagnostics simplify troubleshooting.
High Safety:
Complies with the AS-i Safety at Work specification and relevant safety standards.
Easy Installation and Configuration:
DIN rail mounting and intuitive software configuration.
Precautions
Correct Selection:
Choose the appropriate model based on the application's safety requirements, required safety functions, and AS-i network size.
Correct Installation:
Follow Bihl+Wiedemann's installation guidelines, ensuring the device is securely mounted and the AS-i network is wired correctly.
Safety Circuit Design:
Integrate the BWU2729 into a safety circuit that complies with relevant safety standards.
Parameter Configuration:
Use the AS-i Safety Monitor software to correctly configure safety parameters and safety logic.
AS-i Network Planning:
Ensure the AS-i network complies with specifications, including cable length, power budget, and number of slaves.
Regular Inspection and Testing:
Regularly check the operating status and safety functions of the device, and perform functional tests to ensure proper operation.
Follow Safety Regulations:
Always comply with relevant safety regulations during operation and maintenance.
Product Applications
Machine Safety:
Monitoring emergency stop buttons, safety gate switches, light curtains, etc.
Implementing emergency stop functions for machines.
Controlling safety-related drives.
Conveyor Technology:
Monitoring safety zones.
Emergency stop protection for belt conveyors.
Packaging Machinery:
Interlocking safety gates and guards.
Robotics:
Monitoring and control of safety zones.
Automated Production Lines:
Integrating various safety functions to ensure the safety of the production process.
