DOLD BG5924.48/60 Safety relays

DOLD BG5924.48/60 Overview

The DOLD BG5924.48/60 is a safety relay belonging to the DOLD (E. Dold Söhne GmbH & Co. KG) BG 5924 series. It is typically used in safety circuits to monitor safety functions such as emergency stop buttons, safety gates, and light curtains. The ".48/60" in the model number likely indicates specific voltage ranges or contact configurations.

Product Detailed Description

• Function:

• Monitors signals in safety circuits.

• Reliably disconnects the safety circuit when a hazardous situation is detected (e.g., emergency stop button pressed, safety gate opened), thereby stopping dangerous movements of machines or equipment.

• Features positively driven contacts to ensure safe disconnection even in case of a fault.

• Typically has multiple safety contacts (normally closed - NC) and one auxiliary contact (normally open - NO).

• Employs a dual-channel design for increased safety.

• Features:

• Complies with safety standards such as EN ISO 13849-1.

• Positively driven contacts according to EN 60947-5-1.

• Wide voltage range.

• Plug-in terminals for easy wiring and replacement.

• LED indication for operating status.

• Compact design for space-saving installation.

Product Parameters

As the model number is very specific, the following parameters are based on general knowledge of the BG5924 series and the possible meaning of the model suffix. Always refer to the official datasheet for the specific BG5924.48/60 model for accurate parameters:

• Model: BG5924.48/60

• Safety Contacts: Typically 2 or 3 normally closed (NC) contacts

• Auxiliary Contacts: Typically 1 normally open (NO) contact

• Control Voltage (Uc): 48 V AC/DC or 60 V DC (based on the possible meaning of ".48/60")

• Rated Operating Voltage (Ue): Depends on the contact type and application

• Rated Operating Current (Ie): Depends on the contact type and application

• Contact Material: AgSnO or similar

• Connection Type: Plug-in terminals

• Mounting: DIN rail mounting

• Protection Degree: IP20

• Operating Temperature: Typically -25 °C to +55 °C

• Standards Compliance: EN ISO 13849-1, EN 60947-5-1

• Safety Integrity Level: Up to PL e (EN ISO 13849-1)

Product Advantages

• High Safety: Complies with the highest safety standards, featuring positively driven contacts and a dual-channel design.

• High Reliability: Provides reliable performance in safety-critical applications.

• Easy Installation and Maintenance: Plug-in terminals simplify wiring and replacement.

• Flexible Voltage Range: ".48/60" likely indicates support for multiple control voltages.

• Clear Status Indication: LED indicators facilitate diagnostics.

• Space-Saving: Compact design is suitable for space-limited control cabinets.

Precautions

• Correct Selection: Choose the appropriate model based on specific safety requirements, control voltage, and contact needs.

• Correct Installation: Follow DOLD's installation guidelines, ensuring the relay is securely mounted and wired correctly.

• Safety Circuit Design: Integrate the safety relay into a safety circuit that complies with relevant safety standards.

• Regular Testing: Periodically test the function of the safety relay to ensure it operates reliably when needed.

• Adhere to Safety Standards: Always comply with relevant safety standards and regulations during installation and use.

• Control Voltage Matching: Ensure the control voltage matches the relay's specifications.

Product Applications

DOLD BG5924.48/60 or similar safety relays from the BG 5924 series are widely used in various industrial automation and machinery safety applications, including but not limited to:

• Emergency Stop Circuits: Monitoring the status of emergency stop buttons and safely stopping machines when pressed.

• Safety Gate Monitoring: Monitoring the position of safety gates to prevent dangerous movements when the gate is open.

• Light Curtains and Light Grids: As part of safety interlocking devices, stopping machines when the light beam is interrupted.

• Two-Hand Control: Monitoring the operation of two-hand control buttons to ensure the operator's hands are in a safe area.

• Limit Switches: Monitoring the safe limit positions of machine components.

• General Safety Circuits: For building various safety functions that comply with safety standards.
