Enerpac HPT1500 Two-stage manual hydraulic pump

Enerpac HPT1500 Overview

The Enerpac HPT1500 is a two-speed manual hydraulic pump designed to power a variety of hydraulic tools and equipment. Its two-speed design allows for rapid cylinder advance and then switches to high-pressure output when needed, increasing efficiency.

Product Detailed Description

• Function:

• Provides hydraulic power for hydraulic cylinders, jacks, pullers, and other hydraulic tools.

• Two-speed operation: the first speed delivers high flow at low pressure for fast cylinder advance; the second speed delivers low flow at high pressure for heavy-duty work.

• Built-in safety relief valve to prevent system overload.

• Lightweight and portable for easy use in different work locations.

• Manual operation, requiring no external power source.

• Features:

• Two-speed pump design for increased efficiency.

• Lightweight aluminum construction for easy carrying.

• Integral safety relief valve.

• Handle lock for convenient transportation and storage.

• Optional pressure gauge for precise pressure monitoring.

Product Parameters

• Maximum Operating Pressure:

• 700 bar (10,000 psi)

• Displacement per Stroke:

• First Stage: 13.1 cm³

• Second Stage: 2.3 cm³

• Reservoir Capacity:

• 1500 cm³ (1.5 liters) usable oil volume

• Weight:

• 5.9 kg

• Material:

• Lightweight aluminum base and reservoir

• Handle Effort:

• 36 kg handle effort required at rated pressure

• Oil Port Size:

• 3/8" NPT

• Optional Accessories:

• Pressure gauge assembly

Product Advantages

• High Efficiency:

• Two-speed pump design significantly improves working efficiency, especially in applications requiring long strokes.

• Lightweight and Portable:

• Aluminum construction makes the pump lightweight and easy to transport.

• Safe and Reliable:

• Built-in safety relief valve protects the system from overload damage.

• No Power Required:

• Manual operation makes it suitable for locations without electricity supply.

• Simple Operation:

• Manual operation is intuitive and easy to understand.

Precautions

• Correct Fluid:

• Use only recommended hydraulic oil and keep the fluid clean.

• Oil Level Check:

• Regularly check the oil level in the reservoir and ensure it is within the specified range.

• Pressure Limits:

• Do not exceed the pump's maximum operating pressure.

• Safe Operation:

• Wear appropriate safety gear during operation.

• Avoid rapid or improper operation to prevent damage to the pump or connected equipment.

• Regular Maintenance:

• Periodically inspect the pump's seals and connections to ensure there are no leaks.

Product Applications

The Enerpac HPT1500 manual hydraulic pump is widely used in various applications requiring portable high-pressure hydraulic power, including:

• Industrial Maintenance:

• Powering hydraulic cylinders, bearing pullers, and other tools.

• Construction:

• Operating small hydraulic jacks and spreaders.

• Manufacturing and Assembly:

• Used for clamping, pressing, and other operations.

• Automotive Repair:

• Powering body straightening tools and hydraulic cylinders.

• Emergency Rescue:

• Operating hydraulic spreaders and cutters (typically specialized models).

• Field Service:

• Performing hydraulic operations in remote areas without electricity supply.
