The Fluke 700P09Ex is a high-precision gauge pressure module designed for use with Fluke's intrinsically safe calibrators. This module is specifically engineered for applications in hazardous environments
where explosion-proof equipment is required. It offers accurate pressure measurements in a wide range of units, making it an invaluable tool for calibration, testing, and troubleshooting in various industries.
Key Features and Benefits
High accuracy: Delivers precise pressure measurements with a reference uncertainty of 0.025% (23 ± 3°C).
Rugged construction: Built to withstand harsh conditions and rough handling, ensuring long-term reliability.
Wide pressure range:Measures up to 1500 psi or 10 MPa, accommodating various applications.
Flexible unit selection: Displays pressure readings in 10 different units, providing versatility for different measurement requirements.
Internal temperature compensation: Ensures accurate measurements over a wide temperature range.
Intrinsically safe:Certified for use in hazardous locations, meeting safety standards for explosive atmospheres.
NIST-traceable calibration: Comes with a calibration certificate for confidence in measurement accuracy.
Easy calibration: Can be calibrated locally using the Fluke 700PCK Pressure Calibration Kit.
Specifications
Range: 1500 psi / 10 MPa
Resolution: 0.1 / 0.001
Reference Uncertainty (23 ± 3°C): 0.025%
Total Uncertainty 1 year: 0.050
High Side Media: 316 SS
Low Side Media: N/A
Compensated temperature range: 15°C to 35°C
Precautions
Compatibility: Ensure compatibility with Fluke intrinsically safe calibrators before use.
Calibration: Regular calibration is recommended to maintain accuracy.
Environmental conditions: Avoid exposing the module to extreme temperatures, humidity, or corrosive substances.
Safety: Always adhere to safety guidelines when working in hazardous environments.
Applications
The Fluke 700P09Ex is widely used in various industries, including:
Oil and gas: For calibrating pressure transmitters and gauges in process control systems.
Chemical processing: For measuring pressure in pipelines and vessels.
Pharmaceutical: For calibrating pressure sensors in manufacturing processes.
Power generation: For testing and calibrating pressure equipment in power plants.
