LVL-S1-G3S-E5V1-NA P+F

Brand: P+F

Model number:LVL-S1-G3S-E5V1-NA

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.25kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

LVL-S1-G3S-E5V1-NA P+F Input module






INQUIRE NOW

Products Name: LVL-S1-G3S-E5V1-NA P+F

PRODUCT DESCRIPTION

< Adjustable background suppression

< Visible red light

< Sturdy plastic housing

< Optical surface made of scratch-resistant glass

Detection range 50 ... 500 mm

Detection range min. 50 ... 150 mm

Detection range max. 50 ... 500 mm

Light source LED

Light type modulated visible red light

Black-white difference (6 %/90 %) < 5 %

Diameter of the light spot 12 mm at 500 mm sensor range

Opening angle 1.5 °

Ambient light limit 12000 Lux

Functional safety related parameters

MTTFd 540 a

Mission Time (TM) 20 a

Diagnostic Coverage (DC) 60 %

Indicators/operating means

Function indicator LED yellow, lights up with receiver lit

Control elements Programming switch for light/dark switching

Control elements Sensing range adjuster

Electrical specifications

Operating voltage UB 10 ... 30 V DC

Ripple 10 %

No-load supply current I0 100 mA

Output

Switching type light/dark on

Signal output 2 PNP, complementary, short-circuit protected, reverse polarity protected

Switching voltage 30 V DC

Switching current max. 200 mA

Switching frequency f 70 Hz

Response time 5 ms

Conformity

Product standard EN 60947-5-2

Approvals and certificates

EAC conformity TR CU 020/2011

UL approval cULus

CCC approval CCC approval / marking not required for products rated ≤36 V

Ambient conditions

Ambient temperature -20 ... 60 °C (-4 ... 140 °F)

Storage temperature -20 ... 75 °C (-4 ... 167 °F)

Mechanical specifications

Housing width 26.8 mm

Housing height 91 mm

Housing depth 67.6 mm

Degree of protection IP65

Connection 4-pin, M12 x 1 connector

Material

Housing Terluran® GV15

Optical face glass

Mass 180 g

Background suppression sensor RL23-8-H-500-RT/47/92

2

Germany: +49 621 776 1111 Pepperl+Fuchs Group

Refer to "General Notes Relating to Pepperl+Fuchs Product Information".
