ML4.2-R/40b/95/110 Pepperl+Fuchs Photoelectric Sensors

Pepperl+Fuchs ML4.2-R/40b/95/110 Overview

The Pepperl+Fuchs ML4.2-R/40b/95/110 series are miniature photoelectric sensors belonging to the ML4.2 family. These sensors are typically used as diffuse sensors with background suppression. The specific numbers and letters in the model name indicate particular configurations and features.

Product Detailed Description

• Function:

• Detects the presence or absence of objects.

• Diffuse principle: the sensor emits light, and the output signal changes when the light is reflected back by an object and received by the sensor.

• Background suppression function: reliably detects target objects while ignoring background objects, especially suitable for applications with low color contrast or significant background interference.

• Features:

• Miniature design, saving installation space.

• Reliable background suppression performance.

• Visible red light emitter for easy alignment.

• High switching frequency, suitable for high-speed applications.

• Rugged industrial housing.

Product Parameters

As the model number is very specific, and parameters may vary between sub-models, the following are typical parameters for the ML4.2 series diffuse sensors. Always refer to the official datasheet for the specific ML4.2-R/40b/95/110 model:

• Sensor Type:

• Diffuse sensor with background suppression.

• Sensing Range:

• Varies by specific model, typically from a few millimeters to several centimeters.

• Light Source:

• Visible red light LED.

• Operating Voltage:

• Typically 10 V DC to 30 V DC.

• Output Type:

• PNP or NPN, Normally Open (NO) or Normally Closed (NC), depending on the specific model.

• Connection Type:

• Cable connection or M8/M12 connector.

• Protection Degree:

• Typically IP67.

• Switching Frequency:

• Usually in the hundreds to thousands of Hertz.

• Ambient Temperature:

• Operating temperature range typically from -25 °C to +55 °C.

Product Advantages

• Reliable Background Suppression:

• Effectively suppresses background interference, improving detection reliability.

• Miniature Design:

• Suitable for space-constrained applications.

• Easy Alignment:

• Visible red light facilitates alignment with the target object.

• High Cost-Effectiveness:

• Good balance between performance and price.

• Rugged and Durable:

• Suitable for industrial environments.

Precautions

• Correct Installation:

• Install and secure the sensor according to the instructions in the product manual, ensuring stability.

• Environmental Conditions:

• Avoid using the sensor in environments exceeding its operating temperature and humidity ranges.

• Avoid direct strong light shining on the sensor.

• Power Connection:

• Ensure the power supply voltage is within the allowable range and connect the power and signal wires correctly.

• Target Object Characteristics:

• The sensor's detection performance may be affected by the color, reflectivity, and size of the target object. Choose the appropriate model to suit the specific application.

• Regular Cleaning:

• Regularly clean the optical surface of the sensor to ensure detection accuracy.

Product Applications

• Automation Technology:

• Object detection, counting, positioning.

• Conveyor Technology:

• Detecting objects on conveyor belts.

• Packaging Machinery:

• Detecting packaging materials or products.

• Warehouse Logistics:

• Detecting goods on shelves.

• Access Control:

• Detecting the passage of people.
