MTE RL-00402 Line Reactor

MTE RL-00402 Overview

The MTE RL-00402 is a Line Reactor, part of the RL Series from MTE Corporation. Line reactors are used to protect Variable Frequency Drives (VFDs) and other power electronic equipment from power line transients and surges, and they help reduce harmonic distortion.

Product Detailed Description:

• Function:

• Attenuates transient voltage and current spikes from the power line, protecting VFDs and other sensitive equipment.

• Reduces harmonic currents generated by VFDs, improving power quality and minimizing impact on other equipment.

• Limits inrush current, preventing nuisance tripping of VFDs.

• Improves the power factor of the VFD.

• Features:

• Rugged industrial-grade design.

• Low losses, high efficiency.

• Easy to install and wire.

• Suitable for various AC drive applications.

• UL and cUL listed.

Product Parameters:

As the MTE RL Series includes various models, the following are some typical parameters for the RL-00402. Always refer to the official product manual from MTE Corporation for accurate specifications:

• Inductance: 400 µH (microhenries)

• Rated Current: Needs to be determined based on the specific application and VFD power. The RL Series has models with different current ratings. Please check the product label or official manual.

• Rated Voltage: Typically suitable for 480V AC or 600V AC systems, depending on the model. Please check the product label or official manual.

• Frequency: 50/60 Hz

• Protection Class: Typically open type or IP20, requires installation inside a control cabinet.

• Insulation Class: Typically UL recognized insulation class.

• Temperature Rise: Complies with UL standards.

• Terminal Type: Bolt-down terminals.

• Mounting Style: Foot mount.

• Weight: Needs to be determined based on the specific model. Please check the product label or official manual.

Product Advantages:

• Protects VFDs: Effectively safeguards VFDs from damage caused by power line disturbances and surges, extending their lifespan.

• Reduces Harmonics: Lowers harmonic currents generated by VFDs, improving power quality and reducing interference with the power grid and other equipment.

• Improves System Reliability: Limits inrush current, preventing false tripping of VFDs and enhancing the overall system reliability.

• Improves Power Factor: Helps to improve the input power factor of the VFD, reducing reactive power losses.

• Meets Standards: Complies with industry standards such as UL and cUL, ensuring product quality and safety.

Precautions:

• Correct Selection: Choose the appropriate line reactor based on the VFD's rated current and the power supply voltage. The reactor's rated current should be equal to or greater than the VFD's rated current.

• Correct Installation: Install according to MTE's installation guidelines, ensuring the reactor is securely mounted and has adequate ventilation space.

• Correct Wiring: Connect the reactor and VFD correctly according to the wiring diagram, ensuring secure and reliable connections.

• Grounding: Ensure the reactor enclosure is properly grounded for safety.

• Environmental Conditions: Ensure the operating environment temperature and humidity are within the reactor's permissible range. Avoid use in environments with corrosive gases or excessive dust.

• Regular Inspection: Periodically inspect the reactor's appearance and wiring to ensure there is no damage or loosening.

Product Applications:

Line reactors are widely used in various industrial and commercial sectors that utilize VFDs and other power electronic equipment, including but not limited to:

• Motor Drive Systems: Protecting and improving VFDs used to control pumps, fans, compressors, conveyors, etc.

• HVAC Systems: Reducing harmonics generated by VFDs in heating, ventilation, and air conditioning systems.

• Water Treatment Systems: Protecting VFDs used to control water pumps.

• Manufacturing Automation: Protecting VFDs used to control various automated equipment.

• Elevators and Cranes: Improving the reliability and power quality of drive systems.

• Power Conversion Equipment: Protecting rectifiers, inverters, and other power electronic devices.
