STPS12045TV STMicroelectronics

Product Description

The STPS12045TV is a dual Power Schottky rectifier suited for Switched Mode Power Supplies

and high frequency DC to DC converters. Packaged in ISOTOP, this device is especially intended

for use in low voltage, high frequency inverters, free wheeling and polarity protection applications.

Description:

Product Parameters

• Forward voltage drop: 0.67 V

• Reverse current: 2 A

• Forward current: 120 A

• Peak reverse voltage: 45 V

• Junction temperature: 150 °C

• Storage temperature: -55 to + 150 °C

Product Advantages

• Very small conduction losses

• Negligible switching losses

• Extremely fast switching

• Low thermal resistance

• Insulated package

Precautions

• The STPS12045TV should be installed by a qualified technician.

• The device should be protected from moisture and dust.

• The device should not be operated in an explosive atmosphere.

Product Applications

The STPS12045TV is used in a variety of applications, including:

• Switched mode power supplies

• DC to DC converters

• Inverters

• Free wheeling

• Polarity protection
