VIPA 972-0DP10 PROFIBUS connector

Product Description

The VIPA 972-0DP10 is a high-quality PROFIBUS connector designed for industrial automation applications. It is specifically engineered to provide a reliable and robust connection between PROFIBUS devices and

the bus network. This connector features a 90-degree orientation, making it ideal for tight spaces and improving cable routing.

Key Features and Specifications

• Connector Type: PROFIBUS



• Orientation: 90 degrees



• Material: Die-cast zinc for durability and resistance to interference



• LED Indicators: Integrated LEDs for easy diagnosis of bus activity, termination resistors, power supply, and bus status.



• Termination Resistor: Switchable termination resistor for flexible network configuration.



• Mounting: Captive single-screw mounting system for secure installation.

• Cable Compatibility: Supports a wide range of stranded wire types.

• Environmental: Designed for industrial environments and meets relevant safety standards.

Advantages

• Durability: Robust construction ensures long-term reliability in harsh industrial environments.



• Easy Installation: The captive single-screw mounting system and clear LED indicators facilitate quick and easy installation.

• Diagnostic Capabilities: Integrated LEDs provide real-time feedback on the status of the bus network, aiding in troubleshooting.



• Flexibility: Switchable termination resistor allows for customization to different network configurations.



• Compatibility: Compatible with a wide range of PROFIBUS devices and networks.

Precautions

• Installation: Follow the manufacturer's instructions carefully to ensure correct installation and wiring.

• Torque: Ensure that the mounting screws are tightened to the specified torque.

• Environment: Avoid exposing the connector to excessive heat, cold, or humidity.

• Cable: Use the recommended cable types to ensure optimal performance.

Applications

The VIPA 972-0DP10 is widely used in various industrial automation applications, including:

• Factory Automation: Connecting PROFIBUS devices in production lines and automation systems.

• Process Automation: Integrating PROFIBUS devices into process control systems.

• Building Automation: Connecting PROFIBUS devices in building automation systems.

Additional Information

• Data Sheet: Refer to the official VIPA product data sheet for detailed specifications and technical information.

• Compatibility: Ensure compatibility with other PROFIBUS devices and networks.

• Maintenance: Regular inspection and maintenance are recommended to ensure optimal performance.
