VQZ332-5Y1-02 SMC

The removal of the source of the malfunction or a reset can result in anautomatic restart of the drive. lf, for safety reasons, this is not permissible for thedriven machine, disconnect the unit from the supply system before correcting thefault.

Never install damaged products or take them into operation. Please submit acomplaint to the transport company immediately in the event of damage.Installation, startup and service work on the unit only by trained personnel. Thepersonnel must be trained in the relevant aspects of accident prevention and mustcomply with the regulations in force (e.g. EN 60204，VBG 4，DIN-VDE0100/0113/0160).

Follow the specific instructions during installation and startup of the motor andthe brake!

Make sure that preventive measures and protection devices correspond to theapplicable regulations (e.g. EN 60204 or EN 50178).Grounding the unit is a necessary protective measure.Overcurrent protection devices are a necessary protective measure.

The unit meets all requirements for reliable isolation of power and electronicsconnections in accordance with EN 50178 All connected circuits must also satisfythe requirements for reliable isolation so as to guarantee reliable isolation.Take suitable measures to ensure that the connected motor does not start up automatically when the inverter is switched on. To do this, you can connect binaryinputs DI01 through DI03 to GND.

Connection to the frequency inverter output is only permitted in size 0S, OM and 0Lwhen the output stage is inhibited.

Dangerous voltages are present at the output terminals and the cables andmotor terminals connected to them when the unit is switched on. Dangerousvoltages may also be present when the unit is inhibited and the motor at a standstillThe unit is not necessarily deenergized when the LEDs and the 7-segmentdisplay are off.

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
