WAGO 750-467 Output Module

WAGO 750-467 Overview

The WAGO 750-467 is a 4-channel analog current output module belonging to the WAGO-I/O-SYSTEM 750 series. It is used to convert digital signals from the control system into analog current signals of 0 to 20 mA or 4 to 20 mA for controlling various actuators.

Product Detailed Description

• Function:

• Converts digital data from the controller into analog current signals.

• Provides 4 independent analog current output channels.

• Configurable for 0 to 20 mA or 4 to 20 mA output.

• Electrical isolation of the field side.

• Supports online module replacement.

• Features:

• Compact design, saving control cabinet space.

• High accuracy and resolution.

• LEDs indicate the status of the module and channels.

• Configurable via WAGO-I/O-PRO or other programming software.

• Suitable for various industrial automation applications.

Product Parameters

• Number of Channels:

• 4

• Analog Output Range:

• 0 to 20 mA

• 4 to 20 mA

• Resolution:

• 12 bits

• Load Resistance:

• ≤ 500 Ω

• Accuracy:

• ± 0.1 % (based on full scale)

• Electrical Isolation:

• 500 V system voltage

• Supply Voltage:

• 5 V DC (via system bus)

• Current Consumption (5 V):

• Approx. 30 mA

• Connection Method:

• CAGE CLAMP® connection with spring clamp terminals

• Width:

• 12 mm

• Operating Temperature:

• -20 °C to +60 °C

• Storage Temperature:

• -40 °C to +85 °C

• Protection Class:

• IP20

• Standards:

• EN 61131-2, UL 508

Product Advantages

• Multi-Channel:

• Provides 4 independent analog output channels in a single module, saving cost and space.

• Configurability:

• Flexible configuration for 0-20 mA or 4-20 mA output, adapting to different actuator requirements.

• High Accuracy:

• 12-bit resolution and high accuracy ensure the precision of control signals.

• Easy Installation and Maintenance:

• Compact design and tool-free CAGE CLAMP® connection facilitate installation and wiring.

• Online replacement function reduces downtime.

• High Reliability:

• Industrial-grade design suitable for harsh industrial environments.

• Status Indication:

• LEDs facilitate fault diagnosis and status monitoring.

Precautions

• Correct Wiring:

• Wire correctly according to the wiring diagram in the module manual to avoid short circuits or incorrect connections.

• Power Requirements:

• Ensure the control system provides a stable 5 V DC power supply.

• Load Limitations:

• Ensure that the load resistance of the connected actuators does not exceed the module's maximum permissible value (500 Ω).

• Environmental Conditions:

• Avoid using the module in environments outside its operating temperature and humidity ranges.

• ESD Protection:

• Take appropriate electrostatic discharge (ESD) protection measures when handling the module.

• Software Configuration:

• Use the correct programming software (e.g., WAGO-I/O-PRO) to configure the module, including the output range and calibration.

Product Applications

• Industrial Automation:

• Controlling actuators with analog control, such as valves, frequency inverters, and proportional amplifiers.

• Process Control:

• Controlling process variables such as flow, pressure, and temperature.

• Building Automation:

• Controlling valves and actuators in HVAC systems.

• Machine Manufacturing:

• Controlling hydraulic and pneumatic proportional valves.

• Test and Measurement Equipment:

• Outputting analog signals to control external devices.
