WAGO 750-600 DC/DC Converter Power Modules

WAGO 750-600 Power Supply Module Overview

The WAGO 750-600 is a DC/DC converter power supply module belonging to the WAGO-I/O-SYSTEM 750 series. It is used to provide a stable 24 VDC power supply for WAGO I/O modules and fieldbus controllers.

Product Detailed Description

• Function:

• Converts input voltage to a stable 24 VDC output voltage.

• Supplies power to WAGO 750 series I/O modules and fieldbus controllers.

• Provides electrical isolation.

• Integrated overload protection and short-circuit protection.

• Features:

• Compact design, saving control cabinet space.

• DIN rail mounting, convenient and quick.

• Wide input voltage range, adapting to different power supply environments.

• High efficiency, reducing energy loss.

• High reliability, suitable for industrial applications.

Product Parameters

• Input Voltage Range:

• 24 VDC (20.4 ... 28.8 VDC)

• Output Voltage:

• 24 VDC (nominal voltage)

• Output Current:

• 3 A

• Output Power:

• 72 W

• Electrical Isolation:

• Input/Output 500 VDC

• Efficiency:

• Typ. > 90%

• Overload Protection:

• Output current limitation

• Short-Circuit Protection:

• Automatic recovery

• Connection Type:

• CAGE CLAMP® connection technology

• Mounting Type:

• DIN 35 rail

• Protection Degree:

• IP20

• Ambient Temperature:

• Operating temperature: -20 ... +60 °C

• Storage temperature: -40 ... +85 °C

• Dimensions (W x H x D):

• 24 mm x 100 mm x 72 mm

• Weight:

• Approx. 100 g

• Standards Compliance:

• EN 61010-2-201, UL 508

Product Advantages

• High Reliability:

• Specifically designed for industrial environments, providing a stable power supply.

• High Efficiency:

• Reduces energy loss and saves operating costs.

• Compact Design:

• Saves control cabinet space.

• Easy Installation:

• DIN rail mounting and CAGE CLAMP® connection technology, convenient and quick.

• Comprehensive Protection Functions:

• Integrated overload and short-circuit protection, improving system safety.

• Wide Input Voltage Range:

• Adapts to different power supply environments.

Precautions

• Correct Selection:

• Select the appropriate power supply module based on the total power required by the system.

• Correct Installation:

• Follow WAGO's installation guidelines, ensuring the module is securely fixed and the wiring is correct.

• Environmental Conditions:

• Ensure the operating environment temperature is within the allowable range and avoid humidity and corrosive gases.

• Input Voltage:

• Ensure the input voltage is within the specified range.

• Overload Protection:

• Avoid prolonged overload operation to protect the power supply module.

• Maintenance:

• Regularly check if the module connections are loose and if the surface is clean.

Product Applications

• Industrial Automation:

• Power supply for WAGO I/O systems and fieldbus controllers.

• Used in various industrial control systems such as PLCs and DCSs.

• Mechanical Engineering:

• Provides power for the control systems of machine tools and equipment.

• Building Automation:

• Provides a stable power supply for building control systems.

• Other applications requiring a stable 24 VDC power supply.
