Woodhead 804001A09M050 Connectors

Product Description

The Woodhead 804001A09M050 is a high-performance industrial connector designed for reliable power and signal transmission in harsh environments. Part of the Woodhead line of connectivity solutions, this connector is engineered to withstand extreme conditions, making it ideal for factory automation, heavy machinery, and outdoor applications. Its rugged construction ensures durability, while its precision design guarantees secure and consistent electrical connections.

Product Specifications

Product Advantages

• Durability: Constructed with nickel-plated brass for excellent corrosion resistance and mechanical strength.

• Environmental Protection: IP67 rating ensures protection against dust and water immersion, suitable for outdoor and washdown environments.

• High Performance: Supports up to 7.5A per contact and 250V, ideal for power and signal applications.

• Ease of Installation: Solder cup termination allows for secure and customizable wiring.

• Wide Temperature Range: Operates reliably in extreme temperatures, from freezing cold to high heat.

• Compliance and Safety: Meets RoHS, UL, and CSA standards, ensuring safety and environmental compatibility.

Precautions

• Proper Sealing: Ensure that the connector is properly mated and sealed to maintain its IP67 rating.

• Torque Specifications: Follow manufacturer-recommended torque values when tightening connectors to avoid damage.

• Soldering Care: Use appropriate soldering techniques to prevent cold joints or damage to contacts.

• Cable Strain Relief: Use proper cable glands or strain relief to prevent mechanical stress on the connector.

• Compatibility: Verify mating connector compatibility to ensure proper fit and function.

Product Applications

• Factory Automation: Used in robotic arms, sensors, and control systems requiring robust connectivity.

• Heavy Machinery: Ideal for construction, mining, and agricultural equipment exposed to harsh conditions.

• Outdoor Equipment: Deployed in outdoor lighting, security systems, and communication enclosures.

• Transportation: Applied in railway, marine, and automotive systems for reliable power and signal transmission.

• Renewable Energy: Used in solar and wind energy systems for interconnecting components in exposed environments.

• Food and Beverage: Suitable for washdown areas in food processing plants due to its IP67 rating.
