XX500A0KC00L3 Telemecanique

Main

Range of Product Telemecanique Ultrasonic sensors XX

Sensor Type Ultrasonic sensor

Series name General purpose

Sensor name XX5

Sensor design Cylindrical M12

Detection system Diffuse

[Sn] nominal sensing

distance

0.16 ft (0.05 m) fixed

Material Plastic

Type of output signal Discrete

Discrete output function 2 NO

Wiring Technique 4-wire

Discrete output type PNP and NPN

[Us] rated supply

voltage

12...24 V DC reverse polarity protection

Electrical connection Cable M8 4 pins, 9.84 ft (3 m)

[Sd] sensing range 0.02…0.17 ft (0.0064…0.051 m)

Beam angle 11 °

IP degree of protection IP67 conforming to IEC 60529

Complementary

Enclosure Material ULTEM

Front material Epoxy

Thread type M12 x 1

Supply voltage limits 10…28 V DC

[Sa] assured operating distance 0.02…0.17 ft (0.0064…0.051 m)

Maximum differential travel 0.03 in (0.7 mm)

Blind zone 0.00…0.25 in (0…6.4 mm)

Transmission frequency 500 kHz

Repeat accuracy 0.7 %

Deviation angle from 90° of object to be detected -10…10 °

Minimum size of detected object Cylinder diameter 2.5 mm

Flat bar 1 mm wide

Status LED Supply on 1 LED green)

Output state 1 LED yellow)

Current Consumption 25 mA

Maximum switching current 100 mA overload and short-circuit protection

Maximum voltage drop 1 V

Switching frequency <= 125 Hz

Maximum delay first up 20 ms

Maximum delay response 2 ms

Maximum delay recovery 2 ms

Marking CE

Threaded length 1.50 in (38 mm)

Height 0.47 in (12 mm)

Width 0.47 in (12 mm)

Depth 1.97 in (50 mm)

Net Weight 0.02 lb(US) (0.011 kg)
