2814744 MCR-S10-50-UI-SW-DCI-NC Phoenix

Brand: Phoenix

Model number:2814744 MCR-S10-50-UI-SW-DCI-NC

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.25kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

2814744 MCR-S10-50-UI-SW-DCI-NC Phoenix  I/O module




INQUIRE NOW

Products Name: 2814744 MCR-S10-50-UI-SW-DCI-NC Phoenix

PRODUCT DESCRIPTION

The new STEP POWER generation of compact power supply units is particularly suitable for installation distributors

and flat control panels thanks to its design. The power supply units are available with 24 V DC output voltage in various

performance classes and widths and with the special voltages 5, 12, 15 and 48 V DC. Their high degree of efficiency and

the low standby losses make for high power efficiency.

2814744 MCR-S10-50-UI-SW-DCI-NC Phoenix

Height 90 mm

Depth 61 mm

Weight 0.1 kg

Efficiency > 84 % (for 230 V AC and nominal values)

Insulation voltage input/output 4 kV AC (type test)

2 kV AC (routine test)

Degree of protection IP20

Class of protection II

MTBF > 500 000 h in acc. with IEC 61709 (SN 29500)

Ambient temperature (operation) -25 °C ... 70 °C (> 55° C derating)

Ambient temperature (storage/transport) -40 °C ... 85 °C

Max. permissible relative humidity (operation) ≤ 95 % (at 25 °C, no condensation)

Mounting position Horizontal DIN rail NS 35, EN 60715

Assembly instructions Can be aligned: Horizontal 0 cm, vertical 3 cm

Electromagnetic compatibility Conformance with EMC directive 2004/108/EC

Immunity to interference EN 61000-6-2:2005

Low Voltage Directive Conformance with LV directive 2006/95/EC

Standard – Electrical equipment of machines EN 60204

Standard - Safety of transformers IEC 61558-2-17

Standard - Electrical safety IEC 60950/VDE 0805 (SELV)

Standard – Electronic equipment for use in

electrical power installations and their assembly

into electrical power installations

EN 50178/VDE 0160 (PELV)

Standard – Safety extra-low voltage IEC 60950 (SELV) and EN 60204 (PELV)

Standard - Safe isolation DIN VDE 0100-410

DIN VDE 0106-1010

Standard – Protection against electric shock DIN 57100-410

Standard – Protection against shock currents,

basic requirements for protective separation in

electrical equipment

DIN VDE 0106-101
