Phoenix 2313685 D-sub connector

Product Description

The Phoenix Contact 2313685 is a D-sub connector designed for industrial automation applications. Specifically, it's part of the SUBCON-PLUS series, which offers robust and reliable connectors suitable for harsh environments. This particular model is a 9-pin, right-angle connector with a PG protective sleeve, making it ideal for connecting devices in confined spaces or where a specific cable orientation is required.

Key Features and Specifications

• Connector Type: D-sub

• Number of Pins: 9

• Orientation: Right-angle

• Protective Sleeve: PG

• Bus System: PROFIBUS DP

• Maximum Data Rate: 12 Mbps

• Mounting: DIN rail mountable

• Material: Housing made of metal-plated ABS

• Certifications: CSA, UL Recognized, cULus Recognized, EAC

Advantages

• Robust Construction: Designed to withstand harsh industrial environments.

• Versatility: Suitable for a wide range of applications due to its modular design and various mounting options.

• Reliable Connections: Ensures secure and reliable electrical connections.

• Easy Installation: Quick and easy to install with the provided mounting hardware.

• Compatibility: Compatible with PROFIBUS DP networks.

Precautions

• Torque: Ensure proper tightening of the screws to avoid damage to the connector.

• Environment: Avoid exposing the connector to excessive heat, cold, or humidity.

• Cable Selection: Use the appropriate cable and ensure proper shielding to minimize interference.

• Grounding: Proper grounding is essential for electrical safety.

• Polarity: Observe correct polarity when connecting the connector to the device.

Applications

The Phoenix Contact 2313685 is commonly used in various industrial automation applications, including:

• Factory Automation: Connecting PLCs, sensors, actuators, and other devices in automated systems.

• Process Control: Used in data acquisition and control systems for various processes.

• Robotics: For connecting robot controllers and peripherals.

• Machine Vision: Used in machine vision systems to connect cameras, lighting, and other components.

Additional Information

• Accessories: A wide range of accessories is available, such as cable assemblies, strain relief clamps, and mounting brackets.

• Customization: The connector can be customized to meet specific application requirements.

• Data Sheet: Refer to the official Phoenix Contact product data sheet for detailed specifications and technical information.

For more detailed information and specific product recommendations, please refer to the Phoenix Contact product catalog or consult with a Phoenix Contact authorized distributor.
