PS/1AC-240V/24DC/40A Phoenix Central control module

Phoenix Contact PS/1AC-240V/24DC/40A Overview

The Phoenix Contact PS/1AC-240V/24DC/40A is a high-performance single-phase power supply unit belonging to the QUINT POWER series from PHOENIX CONTACT. This power supply provides a reliable 24 V DC output with a current of up to 40 A, suitable for a wide range of industrial automation and control applications.

Product Detailed Description

• Function:

• Converts single-phase AC input voltage to a stable 24 V DC output voltage.

• Provides an output current of up to 40 A to meet high-power application requirements.

• Features SFB (Selective Fuse Breaking) technology for fast and reliable tripping of standard circuit breakers in the event of a short circuit.

• Offers a Power Boost function that provides up to 1.5 times the nominal current for a short period to start heavy loads.

• Incorporates preventive function monitoring to report critical states before a fault occurs.

• Wide input voltage range for global use in various power supply systems.

• Compact design to save installation space.

• Features:

• Single-phase input.

• Regulated 24 V DC output.

• 40 A output current.

• SFB technology.

• Power Boost function.

• Preventive function monitoring.

• Wide input voltage range: 85 V AC to 264 V AC.

• High efficiency.

• DIN rail mounting.

• High reliability and long service life.

Product Parameters

• Input Voltage Range:

• 85 V AC to 264 V AC (single-phase)

• Input Frequency Range:

• 45 Hz to 65 Hz

• Input Current:

• 5.5 A (at 230 V AC)

• Output Voltage:

• 24 V DC (±1%)

• Output Current:

• 40 A (at +60 °C ambient temperature)

• Power Boost:

• 60 A for 5 s

• SFB Circuit Breaker Tripping:

• 12 A to 25 A (Circuit breaker type B)

• 16 A to 32 A (Circuit breaker type C)

• Efficiency:

• Typ. 93%

• Power Loss:

• < 0.9 W (at idle)

• Typ. 30 W (at nominal load)

• Connection Method:

• Screw connection

• Mounting Type:

• DIN rail NS 35

• Degree of Protection:

• IP20

• Ambient Temperature Range:

• -25 °C to +70 °C (derating applies)

• Dimensions (W x H x D):

• 96 mm x 130 mm x 125 mm

• Weight:

• 1.4 kg

• MTBF (Mean Time Between Failures):

• 700,000 h

• Approvals:

• CE, UL/cUL (UL 508 Listed), EAC, CB, etc. (refer to the specific product manual)

Product Advantages

• High Power Output:

• Provides up to 40 A of current, suitable for applications requiring high power.

• High Reliability:

• The QUINT POWER series from Phoenix Contact is known for its high reliability and long service life.

• SFB Technology:

• Reliably and quickly trips standard circuit breakers for selective protection, preventing the shutdown of the entire system.

• Power Boost Function:

• Enables easy starting of loads with high inrush currents.

• Preventive Function Monitoring:

• Reports potential problems in advance, increasing system availability and reducing downtime.

• Global Applicability:

• Wide input voltage range allows for use in various power supply systems worldwide.

• Easy Installation:

• Compact design and DIN rail mounting simplify installation.

• High Efficiency:

• Typical efficiency of 93% helps reduce energy consumption and heat dissipation.

Precautions

• Correct Selection:

• Select the appropriate power supply unit based on the current requirements and peak currents of the load.

• Correct Installation:

• Follow the installation guidelines from Phoenix Contact, ensuring the power supply unit is installed in a well-ventilated area with suitable ambient temperature.

• Correct Wiring:

• Connect the input and output terminals correctly according to the wiring diagram, ensuring proper grounding.

• Derating:

• Consider derating the output current when operating at higher ambient temperatures. Refer to the derating curve in the product manual.

• Protection Measures:

• Although the power supply unit has built-in protection functions, consider additional overcurrent and overvoltage protection measures in the system design.

• Regular Inspection:

• Regularly check the operating status and connections of the power supply unit to ensure proper functioning.

Product Applications

The Phoenix Contact PS/1AC-240V/24DC/40A power supply unit is widely used in various industrial automation and control fields, including:

• Industrial Control Systems:

• Providing stable power for control devices such as PLCs, HMIs, sensors, and actuators.

• Machine Building:

• Powering machine tools, automated equipment, and robots.

• Process Automation:

• Supplying power to various devices in process control systems.

• Building Automation:

• Powering HVAC systems, lighting control, and security systems.

• Logistics Automation:

• Supplying power to conveyor systems, sorting equipment, and warehouse systems.

• Packaging Machinery:

• Providing reliable power for various packaging equipment.
