QUINT-PS-100-240AC/24DC/2.5 Phoenix Power Module

Brand: Phoenix

Model number:QUINT-PS-100-240AC/24DC/2.5

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.25kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

QUINT-PS-100-240AC/24DC/2.5 Phoenix Power Module




INQUIRE NOW

Products Name: QUINT-PS-100-240AC/24DC/2.5 Phoenix Power Module

PRODUCT DESCRIPTION

Phoenix Contact QUINT-PS-100-240AC/24DC/2.5 Overview

The Phoenix Contact QUINT-PS-100-240AC/24DC/2.5 is a high-performance single-phase power supply belonging to the QUINT POWER series. It combines a wide input voltage range with a compact design, high reliability, and intelligent functions.

Product Detailed Description

  • Function:

    • Converts AC input voltage into a stable 24 V DC output voltage.

    • Provides a reliable power supply for various industrial applications.

    • Features a Power Boost for the reliable starting of heavy loads.

    • Offers preventive function monitoring, signaling before a fault occurs.

    • Provides short-circuit and overload protection.

  • Features:

    • Wide input voltage range: 85 V AC to 264 V AC.

    • Compact design saves space in the control cabinet.

    • High reliability with a high Mean Time Between Failures (MTBF).

    • Power Boost for the reliable starting of heavy loads.

    • Preventive function monitoring provides status information via active switching output and LED indicator.

    • Robust short-circuit and overload behavior.

    • Parallel operation possible for increased power or redundancy.

Product Parameters

  • Input Voltage Range:

    • 85 V AC to 264 V AC (single-phase)

  • Input Frequency Range:

    • 45 Hz to 65 Hz

  • Output Voltage:

    • 24 V DC ± 1%

  • Output Current:

    • 2.5 A (at +60 °C ambient temperature)

    • 3 A (Power Boost, duration 5 s)

  • Output Power:

    • 60 W

  • Efficiency:

    • Typ. 90% (at 230 V AC input and nominal load)

  • Residual Ripple:

    • < 50 mVpp

  • Connection Method:

    • Screw connection

  • Mounting Type:

    • DIN rail mounting

  • Protection Degree:

    • IP20

  • Ambient Temperature Range:

    • -25 °C to +70 °C (derating from +60 °C)

  • MTBF (Mean Time Between Failures):

    • 500,000 hours

  • Dimensions (W x H x D):

    • 32.5 mm x 130 mm x 115 mm

  • Weight:

    • Approx. 0.3 kg

  • Certifications:

    • CE, UL, cUL, EAC, CB, etc. (refer to the specific product manual)

Product Advantages

  • High Reliability:

    • Long MTBF ensures stable system operation.

  • Universally Applicable:

    • Wide input voltage range makes it suitable for different power grids worldwide.

  • Power Boost:

    • Power Boost function ensures reliable starting of loads with high inrush currents.

  • Preventive Monitoring:

    • Early fault detection helps to minimize downtime.

  • Space-Saving:

    • Compact design saves valuable space in the control cabinet.

  • Easy Installation:

    • DIN rail mounting and screw connections simplify the installation process.

  • Parallel Functionality:

    • Can be connected in parallel to increase output power or for redundancy.

Precautions

  • Correct Installation:

    • Follow Phoenix Contact's installation guidelines to ensure proper mounting and cooling of the power supply.

  • Power Requirements:

    • Ensure the input voltage is within the permissible range.

  • Environmental Conditions:

    • Avoid using the power supply in environments exceeding its operating temperature range.

  • Overload Protection:

    • Although the power supply has overload protection, continuous overload operation should be avoided.

  • Grounding:

    • Ensure the ground terminal of the power supply is properly connected.

  • Maintenance:

    • The power supply is generally maintenance-free, but its operating status and connections should be checked regularly.

Product Applications

  • Industrial Automation:

    • Power supply for control systems, sensors, and actuators.

  • Mechanical Engineering:

    • Power supply for various machines and equipment.

  • Building Automation:

    • Power supply for automation systems in buildings.

  • Process Engineering:

    • Power supply for process control systems.

  • Other General Industrial Applications:

    • Any application requiring a reliable 24 V DC power supply.
